6 Outdoor Full Color LED Display for Rental with die-casting cabinet size of 576x576mm,high brightness 6000nits, good uniformity
Product Features:
1. SMD led encapsulation confirm wide view angle, up to 140 degree for horizontal and vertical
2.With special craft finished ensure good waterproof IP65, anti-corrosion and rust-proof
3.High pixel density, high resolution,high definition
4. With Rental design strong configuration die-casting Aluminum Cabinet, easy and quick to assemble without tools in short time and long life time
5. Cabinet with no fan design and aluminum material confirm low power consumption, low noise created,
6. Can be fixed installation or for rental to meet the request of live broadcast, live meeting, banquet, party, etc, to display the content what you want, connect with PC computer or network
7.Widely used for commercial display, stage background, mobile advertising. Traffic led sign, sports scoreboard etc.
| P6 SMD3535 Indoor full Color LED Screen Specification |
| Pixel pitch | 6mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD3535 |
| Size of module | 288mm*288mm |
| Resolution of module | 48x48 |
| Size of cabinet | 576mm x 576mm x 65mm |
| Resolution of cabinet | 96x96 |
| Material of Cabinet | Die-casting Aluminum |
| Weight of Cabinet | 12.50KGS |
| Brightness | >6000cd/ |
| Density | 27777dots/ |
| Best viewing angle | 140 /140 |
| Pixel Configuration | 1R1G1B |
| Best viewing distance | 5-60M |
| Maximum power consumption | 1000W/ |
| Average power consumption | 560W/ |
| Driving method | 1/8 scan |
| Control method | Synchronization |
| Gray scale | 65536 |
| Colors | 256*256*256 |
| Color temperature | 3200-9300k |
| Uniformity | 97% |
| Working voltage | AC220V/110V±10% |
| Working temperature | -20ºC~+50ºC±10% |
| Working humidity | 10% ~ 90% |
| MTBF | 10,000 hours |
| Frame frequence | 50/60Hz |
| Refresh frequence | >1920Hz |
| IP grade | IP65 |
| Life Span | 100,000 hours |
| Data transafer method | RJ45 |
| Pratical standard | CCC TUV-CE ETL etc. |
Effectivce Communication
Distance(without relay) | Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM |
| Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc. |
| Systems operating platform | WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development |
