| Price: | US $ 700-1200/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T |
| Item | Value |
| Pixel Pitch(mm) | 25 |
| Pixel Density(pixels/m2) | 1600 |
| Pixel Configuration | DIP 1R1G1B |
| Brightness(nits) | ≥6000 |
| Viewing Angle(deg.) | 120(Horizontal), 60(Vertical) |
| Transparent Rate | 40% |
| Driving Mode | Static |
| Grey Level(level) | 65536 |
| Refresh Rate(Hz) | 1920 |
| Frame Rate (Hz) | ≥60 |
| Brightness Adjustment | Manual/ Auto/ Programmable |
| Module Size(mm) | 400(W)×200(H) |
| Module Size(inch) | 15.75(W) × 7.87(H) |
| Module Resolution(pixel) | 16×8 |
| Panel Size (mm) | 800(W)×800(H)×165(D) |
| Panel Size(inch) | 31.50(W)×31.50(H)×6.50(D) |
| Panel Resolution(pixels) | 32×32 |
| Panel Material | Aluminum |
| Panel Weight(kg) | ≤14.5 |
| Voltage(V) | AC 110 ~ AC 220 |
| Avg. Power Consumption (W/m2) | 175 |
| Max. Power Consumption (W/m2) | 525 |
| Serviceability | Rear |
| Protection Grade (Front/Rear) | IP65/IP54 |
| Operating Temp/Humidity (/%RH) | -20~40/ 10~90 |
| Storage Temp/Humidity (/%RH) | -40~60/ 10~90 |
| Lifetime (hours) | ≥50000(Normal Temp) |
| Compliant Standard | CE,FCC,RoHS |
Q:What is your hot sale product?
A:P10 full color is best selling for Outdoor; P6 full color is best selling for indoor.
Q:What different from 1/4 scaning with 1/8 scaning?
A:1/4 scaning is better than 1/8, the screen will be high definition,high brightness.
Q:What different from LCD with LED?
A:1.LED is more energy save than LCD , have a high definition .
2.LED have a big viewing angle, it can up to160 degree.
3.LED can working well in a strong shine day.
Q:How to ensure the good quality of LED display?
A:Optimized structure can improve the efficency of installing screen to creat value;Aging can improve the quality, ensure reliability.
Q:The advantage of LED SMD
A:1.High resolution ;2.Big viewing angle; 3.Rugged ; 4.Vivid Mixture Color Effect ;5.Color Consistency; 6.Enhanced Contrast Ratio;7.Mass Production; 8.Long Service Life.
| Prod Model: | Fox- DIP- P25mm |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Product: | P25 Full Color LED Display |
| Module Size: | 200*200mm |
| LED Display Module Size(mm): | 400(W)×200(H) |
| Brightness Adjustment: | Manual/ Auto/ Programmable |
| IP Grade: | IP 67 |
| Brightness: | 7500CD/M2 |
| LED Display Weight(Kg): | ≤14.5 |
| Best Viewing Distance: | 20-300m |
| Mtbf: | 10000hpurs |
| Life Span: | 100,000hours |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Pitch: | 25mm |
| Pixel Configuration: | 2R,1G,1B |
| Display Function: | Video Display |
| Average Power Consumption: | 300W / m² |
| Pixel Density: | 1600 dot / m² |
| Scanning Mode: | 1/4 Scan |
| Display Type: | LED Video Display |
| Certification: | RoHS |
