| Price: | US $ 389-508/Square Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Square Meter |
| Pay Type: | L/C,T/T,Paypal,Western Union |
| Number | Item | P10 |
| 1 | Pixel pitch | 10mm |
| 2 | Size of modual | 160mm X 160 mm |
| 3 | Resolution of modual | 16 X 16 |
| 4 | Density of pixel | 10000dots/m2 |
| 5 | Pixel configuration | 1R1G1B |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 10-250m |
| 11 | Horizontal viewing angle | 120° |
| 12 | Maximum power consumption | ≤ 1500w/m 2 |
| 13 | Brightness | ≥ 8000cd /m 2 |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 6500k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | 1/4scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | ≥ 300Hz |
| 20 | Working voltage | AC220V/110V± 10% |
| 21 | IP grade | IP67(adjustable) |
| 22 | Working temperature | -20° C~80° C |
| 23 | MTBF | > 10000 hours |
| 24 | Life span | > 100, 000 hours |
| 25 | Defects rate. | ≤ 0.00001(Led display line standard< 0.0001) |
| 26 | Computer operation system | Win XP/Vista/ Win 2000/WIN7 |
| 27 | Video signal | RF, S-Video, RGB, RGBHV, YUV, YC. ect |
Trade Terms:
Payment terms: | -Sample Charge: T/T or Western Union -Paypal; Western Union |
Shipping: | -Delivery within 5-12 working days upon receiving deposit payment |
After-Sales-Service: | -Lifetime with professional engineer support. problem |
Our services :
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remend our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materils only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
Company Information:
FOXGOLDEN GROUP LTD (www.foxgolden.com)is a professional high quality LED display manufacturer. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing. Thanks for 11-year customer trust on FOXGOLDEN.
| Prod Model: | FOX-DIP10 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Module Size: | 160*160mm |
| Warranty Time: | 3-5 Years |
| Production Time: | 5-12 Working Days |
| LED Lamp: | Epistar ,Nichia ,CREE |
| IP Grade: | IP 65 |
| Screen Normal Size: | 4*3m, 5*3m, 6*4m ,7*5m etc |
| Installation Environment: | on The Wall / with Support |
| Material: | Anti-Cold ,Anti-Hot |
| Cabinet Size: | 800*800mm, 960*960mm |
| Viewing Distance: | 8-250m |
| Tube Chip Color: | Full Color |
| IP Rating: | IP65 |
| Pixel Pitch: | 10mm |
| Pixel Configuration: | 1R, 1G, 1B |
| Display Function: | Video Display |
| Pixel Density: | 10000 dot / m² |
| Scanning Mode: | 1/4 Scan |
| Display Type: | LED Video Display |
| Application: | Advertising |
| Certification: | ETL |
| Average Power Consumption: | 1100 W/M2 |
