1-high brightness
2-high definition
3-high refresh rate
4-high stability
5-7 years warranty
Unique requirements of the LED display commercial advertising
The LED display for commercial advertising is customized for the company engaging in outdoor advertising, it is suitable for play commercial advertising in outdoor environment according to his basic requirements hi has the following main technical features.
1-)Demanding strong protection.
Most of the LED display for commercial advertising are operated in outdoor environment they must be working well under the extreme weather or condition therefore it must have strong ability of waterproof and protection against strong wind, thunder, lightning, high temperature, low temperature and corrosion.
2-) Long time running.
The LED display for outdoor advertising are usually running from 6 o'clock in the morning until midnight without any break.
3-) Long lifespan.
To maximize the benefit of the customers the LED display must have a long lifespan of 5 to 8 years in general or even longer.
4-) Energy Saving.
The common LED display consumes a lots of electricity if it work without good saving measures the operational cost of electricity will be very high, no advertising company would like to see that happens.
5-) High brightness.
Especially the spectator need to see the picture on the LED display clearly in sunshine from a certain distance so the brightness of the display must be high enough.
6-) wide viewing angle
To increase attraction for viewers and passersby the LED display need wide viewing angle to capture the attention of any passerby from 10 meter to 1000 meter.
7-) excellent Uniformity and stability for picture.
A lot of advertising are showed in the way of picture so the picture must be showed evenly and stably on the LED display.
8-) Well appearance for long.
The LED display must long maintain in good appearance and prevent from getting worse quickly by the effects of light decay and color fading.
Check the technical products information as below
| No. | Specifications |
|
| 1. | Part No. | P16outdoor full color led display |
| 2. | LED chip | Taiwan/Silan/Cree/Cree Cotco |
| 3. | Physical Pixel Pitch | 16mm |
| 4. | Physical Pixel Density | 3906dots/m 2 |
| 5. | Pixel composition | 2Red, 1Green, 1Blue |
| 6. | Moduel Size | 256mm*128mm |
| 7. | Moduel resolution | 16dots*8dots |
| 8. | Cabinet thickness | < 140 mm |
| 9. | Bracket of cabinet | Easy to install onto the LED cabinet and uninstall. |
| 10. | Brightness | ≥ 6500 nits |
| 11. | Colors | 16.7million |
| 12. | Viewing angle | Horizontal ≥ 120° , Vertical : ≥ 50° |
| 13. | Viewing distance | 16m-48m |
| 14. | Soft Rubber Mask | To protect player and LED display itself. |
| 15. | Scan frequency | ≥ 380Hz
There will be one receive card in each cabinet , so that the LED display won' t sparked. Also it is very easy to move and connetct |
| 16. | Video Frame Rate | ≥ 60Hz |
| 17. | Color temperature | 6500° K to 9300° K adjustable |
| 18. | Control method | Controlled by PC, synchronous display |
| 19. | Life span( half brightness) | ≥ 100, 000 hours |
| 20. | Weight | 70Kg /sqm |
| 21. | IP Grade | IP65 /IP43( front side and rear side) |
| 22. | Average power consumption | 470W/sqm |
| 23. | Peak power consumption | 1140W/sqm |
| 24. | Input voltage | 110~240V |
| 25. | Operating Environment | Temperature: -20+50 Humidity: 10%95%RH |
| 26. | Operating system | Windows 98/2000/ME/XP |
| 27. | Type of video signal | S-video, composite video, RGB, VGA, DVI |
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
