Our factory professionally manufacture follow products
1)single color LED display, dual color LED display, full color LED display.
2)indoor LED display semi-outdoor LED display and outdoor LED display.
3)LED moving sign, variable message signs, LED text display, programmable LED moving message sign board, LED scrolling message signs.
4)LED display screen, LED display board, LED display module, LED display control system.
5)LED video display, LED advertising display, truck mobile LED display, rental LED display, stadium LED display, concert LED display, stage LED display.
6)wireless control LED display board, computer controll LED display.
Main features:
Epistar and Silan brand LED chips, MBI5024 driver IC, Meanwell Power supply, all are famous brand materials
Vivid image and video, rich in describing the details of color
High brightness ≥ 1500 CD/m2, automatically brightness adjust to environment, IP65 and range working temperature design, can meet your indoor using request
Signal and power automatically timing function, automatically running
Remote control, error detection, control center management function, feedback the error by SMS
DOT-DOT correction function support
* Products Advantages:
1) Price Advantage: We have the best competitive price at the market
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!
| Outdoor LED Display P10 SPECIFICATIONS: |
| Numbers | Technical indexes | Specification |
| 1 | Pixel pitch | 10mm |
| 2 | Module size | 160mm×160mm |
| 3 | Module resolution | 16×16 |
| 4 | Module density | 10,000dots/sqm |
| 5 | Pixel configuration | RGB |
| 6 | Red wavelength | 625±2nm |
| 7 | Green wavelength | 525±2nm |
| 8 | Blue wavelength | 470±2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 8m---150m |
| 11 | Horizontal viewing angle | 140° |
| 12 | Vertical viewing angle | 70° |
| 13 | Maximum power consumption | 1000W/sqm |
| 14 | Average power consumption | 335W/sqm |
| 15 | Brightness | ≥8000cd/m2 |
| 16 | Gray scale | 16bits of per color |
| 17 | Color temperature | 12000K |
| 18 | Driving method | 1/4scanning |
| 19 | Frame frequency | 60Hz |
| 20 | Refresh frequency | 300 Hz |
| 21 | Working voltage | AC220V/110V±10% |
| 22 | IP grade | IP67 |
| 23 | Working temperature | -20°C~80°C |
| 24 | MTBF | More than 10,000 hours |
| 25 | Life span | More than 100,000hours |
FACTORY :
Trade Terms
Payment terms: |
-Sample Charge: T/T or Western Union
-35% deposit before production, 65% balance before shipping
-Paypal; Western Union |
Shipping: |
-Delivery within 10-15 working days upon receiving deposit payment |
After-Sales-Service: |
-Lifetime with professional engineer support.
-Within 1 year, supply spare parts for free if the machine has quality
problemOur Services |
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remend our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materils only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
Company Information
FOXGOLDEN GROUP LTD (www.foxgolden.com)is a professional high quality LED display Manufacturer. We are speicficated in LED Display field for 11 years, and have already being the 7 years' Alibaba Golden Supplier. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
