1). Price: We have the best competitive High Cost-effective of Price/ features.
2), Automatic: From selecting LED chip, led encapsulation, PCB soldering, LED module,
Are operated by Automatic machine, improve showing effect of led screen.
3). Quality: From material to product finished, from design to produce, all steps are controlled
By our workshop, that's the guarantee of the reliability.
4). Service: All the life time 11 years is serviced free,
Warranty is up to 6 years, Service time is 24hours x 7 days,
5), Payment: Accept: T/T, L/C, D/P, D/A, MoneyGram, werstern union, and Cash.
* Products list and application area:
A: Outdoor full color LED display: Equally or compactly make the red, green, blue color in one dot,
Equally distribute at the panel, so make the whole led panel, led module, led display.
B: . Apply for physical sports, advertisement, bank, stock exchange, station, port, supermarket,
Telecommunication, school, monitor, restaurant, entertainment, etc.
C: Models P8, P10, P12, P12.5, P16, P20, P25., P31.25mm, led display, led module, LED panel
Characteristic
High brightness
Uniform color, reliable function, long life span.
Widely used in indoor
Good consistency, excellent visual effect.
High resolution,
Big viewing angle,
Rugged,
Vivid mixture color effect,
Color consistency.
| Technique | SMD |
| Pixel structure | 1R1G1B 3in1 |
| Pixel pitch | 4mm |
| Pixel density | 62, 500 dots/Sq. m. |
| Luminance | 2, 500cd/Sq. m. |
| Module dimension | 128mm(W) * 64mm(H) |
| Module resolution | 32 pixel(W) * 16 pixelmm(H) |
| Cabinet dimension | 512 * 512mm |
| Cabinet resolution | 128 * 128 |
| Cabinet area | 0.262 sq. meter |
| Optimal visual distance | > 3m |
| Visual angel | 140 degree (H/V) |
| Max power consumption | ≤ 2600w /Sq. m. |
| Average power consumption | ≤ 850w /Sq. m. |
| Brightness adjustment | Adjust according to the enviroment |
| brightness software (0%-100%adjustable) |
| Gray scale | point by point 4096 gray gradelevels of |
| each color, 16 bits γ correction avilable |
| Drive mode | 1/8 dynamic scan, constant current |
| Frame frequency | ≥ 60HZ |
| Refresh frequency | ≥ 480HZ |
| Input voltage | AC 90~260 volts |
| Operation temperature | -40° C~ +60° C |
| Operation humidity | 10%~90% |
| Input signal | video, s-videl, RGB digital signal etc. |
| Inout signal | S-video, RF, RGB, Yuv, YC, composite^ |
| Control system | DVI card + master control card + receiver card |
| MTBF | > 5000 hrs |
| Life span (50% brightness) | 100, 000 hrs |
| Malfunction dot rate | 1/10000 |
| Ingress protection rate | IP31 |
| Cabinet material | Epoxy paint coated, aluminum / iron |
| Application: | Rental / Permanent installation available |
Know more about the product, please login www.foxgolden.com
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
