p3 indoor full color SMD LED screen
Company Description:
FOXGOLDEN GROUP LTD (www.foxgolden.com)is a professional high quality LED display manufacturer. Since 2004, we have been dedicating to the aim that producing high quality products, and now FOXGOLDEN has been well integrated in terms of R&D, produce, project, capital and marketing.
As a company based on market, we are going to be a world wide famous brand in LED display industrial.
Item |
Full color advertising outdoor dip P10 led display |
Pixel |
Pixel pitch: 3 mm |
Pixel configuration:SMD 1R1G1B |
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm |
Module resolution: 64×64 pixels |
Module |
Module size: 192mmx192mm |
Cabinet size: 960mm×960mm×150mm |
Cabinet material: fixed Iron or rental steel,aluminum |
Gross weight: 25-35kg/sq.m |
Module quantity: 25pcs= 5(w) x 5(h) |
Power consumption : Max.:600W/m² Average:400W/m² |
Screen parameter |
Drive method: 1/16 Constant Current |
Brightness: 3500cd/m² |
IC driver: MBI5024,From Taiwan |
Density: 111111 pixel/m² |
Whole display flatness: ≤ 1mm juncture |
Best view distance: ≥ 3M |
Viewing angle: Horizontal: 140° |
Humidity(RH): ≤ 90~95% |
Working temperature: from -30°C~ +60°C |
Working voltage: AC220V/110V±20% |
Refresh frequency: ≥ 1500Hz(Linsn) |
Protection grade: IP65 |
MTBF: More than 10000hrs |
Life time: 100,000 hrs |
Our service:
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remend our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materils only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consulation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consulation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
Pakage:
LED module: Carton
LED display: Anti-shaking wooden case
Flight case
Amia Xiao---(Saler OXGOLDEN)
Alibaba: cn203931000
MP:0086 13560799149
Website:http://www.foxgolden.com
Foxgolden had been engaged in designing and manufacturing LED display for more than 11
years. Our products have certificates like CE/FCC/RoHS/NQA .
The best quality products and excellent service will be provided to you by our professional
team.
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
