Function and Technology Character:
- Light weight,ultra-slim & fashionable design,good for rental business.
- Excellent heat radiating and superior waterproof design.
- Special Fast lock enable the user to assemble and disassemble each cabinets.
- Suoer flux LED lamp integrates the advantages of SMD LED lamp's wide viewing angle and DIP LED lamp's good elimination of heat,it is a brave and brilliant technological innovation for MR LED to use Super Flux LED display in outdoor to bring more benefits to users.
- Standard cabinet size L480mm*L480mm and Standard module size L240mm*H240mm,users can update P10 led display to p4,p5,P6 LED displays without changing the cabinets,save cost for users.
- Optional Install modes,hoisting or fixing installation,both are OK.
- Standardized production for Cabinet and 6-in-1 packing flight case.Shorten the delivery time for customers.
-
| Item | P10mm outdoor full color super flux |
| Pixel Pitch: | 10mm | LED Type: | Super flux 3-in-1 |
| Pixel density: | 10000 pix/m2 | Driving method: | real 1/2 scan |
| Viewing angle: | 120°V and 120°H | Brightness: | >6000 nits(cd/m2) |
| power consumption: | average 530w/m2, max 900w/m2 |
| Cabinet Material: | Die-casting Aluminium | IP Rating: | front IP65,rear IP54 |
| Cabinet weight: | 10.5 kg/pc |
| Standard Module size: | 240mm×240mm×25mm |
| Standard Cabinet Size for option: | L480mm×H480mm×105mm |
| Working and Storage Humidity: | 20-90% RH |
| Working Voltage: | AC 110v-240v ±10% 50-60Hz |
| Processing: | 14bit-16bit, according to different driver IC and control system |
| Refresh Rate: | 400Hz-4800Hz,accordingto different driver IC and control system |
| Working temperature: | -20-+65 | Application: | outdoor use |
Our Services
1. Guarantee
(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remand our goods for free if there is something wrong with them.
(2) We will provide maintenance for a lifetime and charge for the raw materials only.
2. Technology Training
(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.
(2) We will send our engineers to your country by negotiation.
3. Maintenance and Consultation
(1) We provide full maintenance for a lifetime and charge for the raw materials only.
(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free.
4. Documents and Certification
(1) We provide the operation manual, software, test report and so on.
(2) We can also provide all kinds of certification such as CE, UL and so on.
5. CAD Drawing and Fixing
(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
(2) We will send our engineers to your place if we are expected after our negotiation.
6. Additional service
(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free.
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
