1, big viewing angle
2, uniformity brightness
3, high color saturation
4, high definition
5, vivid, smooth result
SMD 3 in 1 technology is widely used in full color indoor LED display which means that one red, one green and one blue chip are encapsulated in one pixel. All pixels are averagely distributed on the whole LED display.
The outstanding advantages of Indoor SMD full color LED display is with big viewing angle, uniformity brightness, high color saturation, and high definition, vivid, smooth result when playing the texts or images.
Leder's full color SMD LED display is with the features of high stability, convenient for installation and maintenance, rich playing content, quick reaction, low failure rate and so on.
It is well applied to city halls, airports, waiting rooms, railway stations, bus waiting rooms, luxury office buildings, factories, enterprises, etc
| ITEMS | P7.62 |
| Module | Pixel Pitch | 7.62mm |
| Pixel Density | 17222dots/m 2 |
| Led Lamp Type | SMD 3 IN 1 |
| Led Lamp Size | 3.5× 2.8mm |
| Led Configuration | 1R1B1G |
| Module Size | 244× 122mm |
| Module Resolution | 32× 16 |
| Scan Mode | 1/8 duty |
| Drive Mode | Constant Current |
| Cabinet | Cabinet Size | 732× 732mm |
| Cabinet Resolution | 96× 96 |
| Module Quantity | 18 |
| Cabinet Weight | less than 25kg/m 2 |
| Display | Brightness | ≥ 1500cd/m 2 |
| Contrast Ratio | ≥ 2000: 1 |
| Viewing Angles | 140° (H)/140° (V) |
| Min. Viewing Distance | 7.5m |
| Gray Scale(Single Color) | ≥ 12bits/4096 level |
| Colors | 68.7 billion |
| Power Supply | Average Power Consumption | 220w/m 2 |
| Working Voltage | AC 90 to 260V, 50 to 60Hz |
| Control System | Frame Changing Rate | 60 to 85Hz |
| Refresh Rate | 600 to 4000Hz |
| Brightness Adjustment | 0 to 100% |
| Ganma Correction | (-0.5 to 5.0) |
| Color Temperature | 3000 to 9300K |
| Brightness Correction Mode | By Pixel, Module, Cabinet Correction |
| Data input Source | AV, S-Videom, VGI, DVI, HDMI, SDI, DP |
| Control Method | Synchronization with computer |
| Data Transmission Distance | 100mby UTP CAT5; 500m by Multi Optic Fiber; 10km by Single Optic Fiber |
| Operation Environment | Windows(2000, XP, Vista, 7) |
| Reliabilityifespan | Storage Temperature | (-40 to 85)centi degree |
| Working Temperature | (-20 to 50)centi degree |
| Working Humidity | 10% to 90% |
| LIfe span | 100, 000Hrs |
| MTBF | 5000Hrs |
| IP Rating | IP43 |
| Blind Spot Rate | ≤ 0.01% |
The complay review:
Foxgolden Group Ltd is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R & D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer ,FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness , but also makes breakthrough progresses on special usgaes. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and oveerseas market.
FOXGOLDEN provides a full series of LED display products involving various single and dual color , text & image display; indoor single & dual color , full color screen; outdoor single & dual color , full color display; dot matrix module display; traffic applied product;and series of indoor & outdoor module
With cultivation for high-quality production management team and project team , high quality products and local maintenance service; we only achieved 0.001% complaint in product quality for 7 constant years. that's why Foxgolden has received comprehensive attention form LED industrial experts these years!
