Features
Automatically adjust the screen brightness by the light-sensor control system, power saved and environmentally friendly
High refresh rate and frame rate, vivid pictures
Change the advertisements at any time
Online power backup to ensure normal work
Remote networked control
Easy for installation,high transparency, low wind-resistance and waterproof
widely used in building showing
Specification
ParametersValueParametersValue
ModelP8 outdoorRefresh Rate≥400HZ
Pixel pitch8mmBlind spot Rate≤0.01%
Module Size(W×H)256x128mmGray scale per color65536
Module Resolution(W×H)32*16dotsIP Grade(Front/Rear)IP65/IP65
Pixel Density15625dot/sqmPower consumption(max/avg)750 / 400W/sqm.
Brightness7000nitsInput voltage(AC)110~240v
Viewing angle(H/V)150° /150°Operating temperature-20°C~50°C
Best Viewing Distance8-80mOperating humidity10%~90%
Module
Certificate
- Anti-shocking wooden case
- Flight case
- Carton-box
Control System Configuration
Foxgolden adopts the latest technology available on the market, based on its reliability and performance.
On the proScreen range only, Foxgolden can provide the Apple® Mac Mini® control PC instead of the default PC (upon request only). Apple® Mac Mini® is the world's most reliable and energy-efficient desktop computer.
Here's technical specifications of the Apple® Mac Mini® mounted (upon request only) on your Foxgolden LED screen:
Our Services
Our service:
1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information .
Trade Terms:
1.Payment: T/T , 35% deposits before production, 65% balance to be paid before dleiverying (Western Union or Moneygram are welcomed)
2.Production lead time for 10~50pcs: 7days, 50~100pcs:15days
3.Sample can be delivered in 3days
4.Shipping freight are quoted under your requests
5.Shipping port: Shenzhen, Mainland China
6.Discounts are offered based on order quantities
7.MOQ: 1sqm
Company Information
Foxgolden Group
Foxgolden Group is the world's leading high-tech enterprises of LED display development, production and sales. Since its establishment in June 1989, our company has realized the expansion from traditional household-appliance market to communication, computer and digit product field. The main products of the Group include LED screens, control system and undertaking city lighting project. Group focus on customer needs and has been working on building a friendly and win-win relationship with partners.
Description | Technical parameter |
Unit module | Module size | 160*160mm |
Pixel pitch | 10mm |
Pixel density | 10, 000dots/m2 |
Pixel configuration | 1R1G1B |
Led specification | Φ 3ellipse |
Pixel resolution | W: 16dots*H: 16dots |
Cabinet | Dimension | 960mm*960mm*170mm |
Quantities of module | 36pcs |
Power supply | 6pcs |
Thermal discharge | Fan*2pcs |
Total weight | 65kg |
Best viewing angle | 10-100m |
Temperature | Storage: -35° C~+85° C |
Working: -35° C~+85° C |
Thickness | 17cm can adjustable |
Remarks: cabinet size can changed, upon project need. |
Power | Working voltage | AC220V/110V± 10% |
Average power consumption | 300-400W |
Max. Power consumption | ≤ 1000W/sqm |
Current | ≤ 20mA(single LED) |
Control system | CPU | Pentium4 or above |
Operating system | WIN98/2000/NT/XP |
Control method | Synchronization |
Main technical parameter | Driving device | 1/4scanning |
Drive type | Constant Current driver IC |
Refresh frequency | ≥ 400Hz |
Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color |
Brightness of white balance | More than 8000cd/sqm |
Brightness adjustment | 256 levels of each color(R/G/B)by software |
Operating ambient humidity | 10%--95% |
Video signal | PAL/NTSC |
Control system | DVI display card+full color controller card |
MTBF | ≥ 10, 000hours |
Life span | ≥ 100, 000hours |
Flatness | Tolerance of interpixel ≤ 0.3mm |
Tolerance of modules clearance≤ 0.6mm |
Power switch | Automatic switch |
Display mode | 1024*768 |
Communication distance | Unshielded twisted pair net line transmission distance 100m, max transmission distance 200m. Multi-mode Optic fiber transmission distance 500m; Single-mode optic fiber transmission distance 10KM |
Software | LED media player |
Our Services1. Guarantee(1) We guarantee all our displays, modules, parts for two full year. During this time, we will replace or remand our goods for free if there is something wrong with them.(2) We will provide maintenance for a lifetime and charge for the raw materials only. 2. Technology Training(1) We provide the technology training for free, which contains the operation training and maintenance training in the factory.(2) We will send our engineers to your country by negotiation. 3. Maintenance and Consultation(1) We provide full maintenance for a lifetime and charge for the raw materials only.(2) We also provide lifetime consultation by E-mail, call, MSN or other ways for free. 4. Documents and Certification(1) We provide the operation manual, software, test report and so on.(2) We can also provide all kinds of certification such as CE,RoHS ,SGS, UL and so on. 5. CAD Drawing and Fixing(1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.(2) We will send our engineers to your place if we are expected after our negotiation.6. Additional service(1) We provide you the forwarding information, and some other information such as flight box, structure information for your reference for free. Company InformationWe offer complete LED screen service solution to every customer .We ranked 9th in LED industry .We are a LED industry trading platform.We produce new environmentally friendly energy-saving high-tech LED screen.Thanks for 11-year customer trust on FOXGOLDEN. Thanks for 11-year LED material supplier support on FOXGOLDEN.Thanks for 11 -year FOXGOLDEN family constant effort .We have 11-year production experience .We have 11-year designing experience. Trade Terms:Payment terms: | 35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
Packing: | -Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
Shipping: | LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
After-Sales-Service: | -Lifetime with professional engineer support. -Within 1 year, supply spare parts for free if the machine has quality problem |
