UL SAA FCC CE Rohs NEW industrial led high bay light
Overview:
1. PHILIPS LUXEON® T luminous source with LM-80 report.
2. High Reliable MEANWELL® HLG driver with 5 Years Warranty.
3. Over then 100, 000 hours operation life.
4. Available for 60° , 90° And 110° Beam angle.
5. IK10&IP66 Rated.
6. UL, DLC, RoHS, CE, GS, CB, SAA certificated.
7. Patent product with 5 patent certificates.
8. 5 years Warranty
9. The price is much more competitive.
Feathers:
Energy savings, high efficiency Easy to maintenance, with big upgrade spaces and High brightness LED.
Application:
Warehouse lighting,factory lighting,rink lighting,gas station lighting.Parking lots.Shops, Billboards, Buildings, Landscapes.
LS-RL120P (250W HID Replacement)
Specification
Specifications |
| Model | LS-RL120P |
| LED Brand | Philips LUXEON® T |
| Driver Brand | Meanwell HLG series |
| Norminal Wattage | 120W |
| LED Module Quantity | 3 modules |
| Input Voltage | 100-240/277VAC |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | >100lm/w |
| Lamp Rated Lumen output | 12 000 lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | Ra>70 |
| Color Temperature | 4000 5000 or 5700K |
| Photometric Type | 60,90,110 degrees |
| Optimal Operating Temperature | 25ºC |
| Storage Temperatures | '-40ºC~+70ºC |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | < 10% |
| Lumen Maintenance | > 60000 hours -L70, @25 ºC (77 ºF) |
| Body and Shell Materials | Anodized Aluminum |
| IP Rating | IP66 with test report |
| IK Rating | IK10 with test report |
| Certification | CE,ROHS,GS, CB, SAA |
| Optional Function | 1-10V DC or PWM Signal or Resistance Dimming |
| Timer/Photocell Control |
| Warranty | 5 years |
| Ceiling Thickness | 5 to 25 mm /0.2 to 1.0 inches |
| Hole Size | 419 ×285 mm /16.5 ×11.2 inches |
|
| Packing Details |
| Fixture Dimension | 389 x304 x120 mm |
| Fixture Weight | 4.4 kg /9.7 lbs |
| Packing Dimension | 425 x365 x200 mm |
| Packing Weight | 5.2 kg /11.5 lbs |
