FOXGOLDEN is a LED display manufacturer, we have specialized in this business line for 11 years.
Feature:
1. Indoor SMD 3in1 product uses three basic color LED in one narrow pixel when LED assembled.
2. Indoor SMD 3in1 product has a good effect to produce a natural color when a video or graphic is displayed.
3. Indoor SMD 3in1 Product can show texts, graphic, video and so on.
4. It has high brightness and adjustable contrast. This model has a good lighting accordance and has no mosaic.
5. Larging view angle, it also has a better viewing effect for text, graphic and video ects, any LED in each pixel can be respectively repaired.
6. Computer VGA screen with real-time synchronization output, and applies to all types of Internet connections with the media to transmit real-time information.
7. Brightness strong, static driving scan mode, larger power-driven, fully guaranteed brightness.
8. In the visual distance of the screen surface direct sunlight, display clearly visible.
9. A gray 4096 super Grey scale control and Y unlined correct function, color display more than 16.7 trillion, close to natural color.
10. Widely used in stadium, bank, school, restaurant, shopping centre, station, goverment, entertainment centres and so on.
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
Trade Terms
1. Payment: T/T, 35% deposits before production, 65% balance to be paid before delivery
2. Shipping freight are quoted under your requests
3. Shipping port: Shenzhen, Mainland China
4. MOQ: 1sqm
| Description | Technical parameter |
| Unit module | Module size | 128*128mm |
| Pixel pitch | 8mm |
| Pixel density | 15625dots/m2 |
| Pixel configuration | 3 in 1 |
| Led specification | SMD3528 |
| Pixel resolution | W:16dots*H:16dots |
| Cabinet | Dimension | 1024mm*1024mm*110mm |
| Weight | 45 kg/sqm |
| Quantities of module | 64pcs |
| Power supply | 6pcs |
| Thermal discharge | Fan*2pcs |
| Total weight | 50kg |
| Best viewing angle | 10-100m |
| Temperature | Storage: -35degree~+85degree |
| Working: -35degree~+85degree |
| Thickness | 11cm can adjustable |
| Remarks: cabinet size can changed, upon project need. |
| Power | Working voltage | AC220V/110V±10% |
| Average power consumption | 200-350W |
| Max. Power consumption | ≤700W/sqm |
| Current | ≤20mA(single LED) |
| Control system | CPU | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control method | Synchronization |
| Main technical parameter | Driving device | 1/8 or 1/4scanning |
| Drive type | Constant Current driver IC |
| Refresh frequency | ≥400Hz |
| Grey scale/colors | 256 levels of each color(R/G/B)/16.7M color |
| Brightness of white balance | 1500-2800cd/sqm can adjustable |
| Brightness adjustment | 256 levels of each color(R/G/B)by software |
| Operating ambient humidity | 10%--95% |
| Video signal | PAL/NTSC |
| Control system | DVI display card+full color controller card |
| MTBF | ≥10,000hours |
| Life span | ≥100,000hours |
| Flatness | Tolerance of interpixel ≤0.3mm |
| Tolerance of modules clearance≤0.6mm |
| Power switch | Automatic switch |
| Display mode | 1024*768 |
| Communication distance | Network cable-100m,multi-model fiber-500m: single-model fiber-20km |
| Software | LED media player |
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
