Feature and Advantage
1. Waterproof: IP43front, IP40back
2. Best viewing distance: 816-300m
3. White balance brightness: 3000CD/sqm adjustable
4. Horizontal viewing angle: 120degree
5. Working temperatue: -20degree-+80degree
6. Life span: More than 100, 000hours
7. Contrast ratio: 4000: 1
8. Consumption: 380W
Application and Market
1. Application
Wide applied in stadiums, advertisement, banks, securities exchange, stations, shopping malls, postal offices, schools, monitoring, restaurants, entertainment, enterprises etc
2. Market:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, MID East, Eastern Asia, Western Europe
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and our current models
4. Protection of your sales area, ideas of design and all your private information
Trade Terms
1. Package: Wooden package, Air flight case or Carton package
2. Payment: T/T, 50% deposits, 50% balance before delivery 3. Shipping port: Shenzhen
4. Warranty time: 3years
5. Delivery time:
Sample order, 3working days;
10sqm-50sqm, 8-18working days;
50sqm-100sqm, 25-28working days.
| item | P6 |
|
| pixel pitch | 6mm |
|
| module size | 384*192mm |
|
| module dots | 64*32 |
|
| pixel configuration | 1R1G1B |
|
| pixel density(dots/m²) | 27777dots/m2 |
|
| red wavelength | 625±2nm |
|
| green wavelength | 525±2nm |
|
| blue wavelength | 470±2nm |
|
| driving method | 1/4 scanning |
|
| best viewing distance | 16m-300m |
|
| horizontal viewing angle | 120° |
|
| working voltage | AC220V/110V±10% DC5V/12V |
|
| working temperature | -20 degree~+80 degree |
|
| color temperature | 6500K |
|
| control method | synchronization/asynchronization |
| frame frequency | 60Hz |
|
| refresh frequency | 300Hz |
|
| working voltage | AC220V/110C±10% DC5V/12V |
| IP grade | IP 43 |
| MTBF | 10000hours |
| life span | 100,000hours |
| warranty | 3 years |
|
Shenzhen Foxgolden Technology Limited, is one of the most impressing Hi-tech enterprises in China. Since 2004, we have been dedicating to the aim that making high quality products, and have been well integrated with R&D, production, project, capital and marketing.
As a professional and market-oriented LED display manufacturer, FOXGOLDEN not only keeps improving on normal LED display screen, enhances the product's cost-effective and overall market competitiveness, but also makes breakthrough progresses on special usages. Our products, with high quality and competitive prices, spread worldwide and earn excellent public reputation from both domestic and overseas market.
Foxgolden provides a full series of LED display products involving various single and dual color, text & image display; Indoor single & dual color, full color screen; Outdoor single & dual color, full color display; DOT matrix module display; Traffic applied product; And series of indoor & outdoor module.
Our company has provided our indoor & outdoor displays for various kinds of locations and events throughout the world. With high quality and perfect after-sale services, our professional products and solutions are highly complimented by the users, and we also earned high credibility from them.
With cultivation for high-quality production management team and project team, high quality products and local maintenance service; We achieved zero complaint in product quality for 3 constant years. That's why Foxgolden has received comprehensive attentions from LED industrial experts these years.
