P4 mm competitive price slim led module
1. Our Service
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM, any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area, ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
2. Trade Terms
1. Payment: T/T, 30% deposits before production, 70% balance to be paid before dleiverying
2. Shipping freight are quoted under your requests
3. Shipping port: ShenZhen, Mainland China
Specifications:
1)Excellent Quality,Pass ISO9001:2000
2)Low Power Consumption. High brightness
3)Long working hours, Long durability
4)Good Uniformity, High performance
5) Competitive price, Timely delivery
smd indoor 320x160 rgb p5 led module
Product Description
1. 320x160 rgb p5 led module parameter :
320x160 rgb p5 led module indoor led screen module |
Item | Parameter | Unit |
Pixel Pitch | 5 | mm |
Resolution of Module | 64×32 | dots |
Module Size | 320×160 | mm |
Module Weight | 0.24 | kg |
Pixel Configuration | SMD2121 1R1G1B |
drive method | high refresh rate |
Pixel Density | 40,000 | dots/sqm |
Brightness (White Balance) | ≥1300 | nits(cd/sq.m) |
Red Wavelength | 620-625 | nm |
Green Wavelength | 520-525 | nm |
Blue Wavelength | 470-475 | nm |
Scan Mode | 1/16 Scan or 1/8 Scan optional |
Viewing Distance | 3--35 | M |
Best View Distance | 5--15 | M |
Viewing Angle-Horizontal | 120 | deg. |
Viewing Angle-Vertical | 120 | deg. |
Module Maximum Power | 25 | W |
Max. Power Consumption | 6,00 | W/sq.m |
Avg. Power Consumption | 300 | W/sq.m |
Working Voltage | 5V 40A |
Power Supply | AC 110/220V |
Refresh Rate | 1,000 | Hz/S |
Frame Rate | ≥ 60 | Hz/S |
Gray Scale | 4096 grades gray |
Display Color | 256*256*256 |
Display Function | Text,news,advertising,flash,animation |
Input Signal | RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc. |
Luminance Degradation | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25°C. |
Defective Dot Rate | <0.0001 |
Life Span | 100,000 | hours |
MTBF | >5,000 | hours |
Storage Temperature | 45 | °C |
Working Temperature | -20 -- +60 | °C |
Working Humidity | 10-90%RH |
Control System | Synchronization or Asynchronization |
Quality Certificate | ECE,RoHS,TUV,ISO9001:2008 |
Warrenty | 2 Years |
Working Environment | Indoor |
Advantages
320x160 rgb p5 led module advantage:
1) High refresh rate and high contrast which make the screen without any delay and smear phenomenon under direct sunlight.
2)Low electric current,high-bright lamps,equipped with PFC switching power supply that save 30% electricty.
3)Environment protection, antistatic, dust-proof, good heat dissipation, cost-effective .
4)Error detection and monitoring:it can monitor the inner temperature,voltage,cooling fans etc and error detection automatically.
5) High reliability: using distributed scanning technology and module design technology that make higher reliability and stability.
6) Steady and reliable system:with strong anti-interference ability and long service life that can continually work for over 24 hours, and it's easy to operate the system.
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
