SMD full color rental led display for exhibitions
High brightness with low power comsumption.
Stabel lifespan.
Flatness gap between cabinets.
standarlization frame in case update.
Easy installation charactristic.
Shenzhen CLC is specialized in LED display, LED display screen, outdoor led display, advertising led display and LED billboard. we offer good products and customized solution that meet the need of our customers.
The LED application products research and develop by CLC has full range and structure diversification, its products cover LED full color display for indoor and outdoor, LED advertisement display, LED stage display, LED irregular-shape display, LED display for taxi, LED sports display, LED traffic information display, which has been dominated in demestic and international market in this industry.
Outdoor LED Display Feature
1. CLC full color outdoor led display has high brightness and adjustable contrast. This model has a good lighting accordance and has no mosaic.
2. CLC outdoor LED display has larging view angle, it also has a better viewing effect for text, graphic and video ects, any LED in each pixel can be respectively repaired.
3. Computer VGA outdoor display with real-time synchronization output, and applies to all types of Internet connections with the media to transmit real-time information.
4. CLC led screens have brightness strong, static driving scan mode, larger power-driven.
5. In the visual distance of the full color LED sign surface direct sunlight, display clearly visible.
6. A gray 4096 super Grey scale control and Y unlined correct function, color display more than 16.7 trillion, close to natural color.
7. CLC led display screen has automatic brightness adjustment function, in different light conditions can attain the best effectives.
8. CLC full color led display can widely used in stadium, bank, school, restaurant, shopping centre, station, goverment, entertainment centres and so on.
9. CLC is a professional LED stage display ,LED Outdoor video wall , Wedding LED display,The stage LED electronic screen,LED large screen full color display,advertising led display,outdoor led display,indoor led display manufacturer.
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM, any your customized lightings we can help you to design and put into product
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
6. Chipshow can offer you LED stage display, LED outdoor video wall, wedding LED display, stage LED electronic screen and led large screen full color display.
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 30% deposits before production, 70% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, Mainland China
5. Warranty time: 2 years
6. Delivery time: 3-12 working days
CLC Full Color Outdoor LED Display Case
No. | Specifications |
|
| 1. | LED chip | Taiwan/Silan/Cree/Cree Cotco |
| 2. | Physical Pixel Pitch | 10mm |
| 3. | Physical Pixel Density | 10000dots/m 2 |
| 4. | Pixel composition | 1Red, 1Green,1Blue |
| 5. | Moduel Size | 160*160mm |
| 6. | Moduel resolution | 16*16dots |
| 7. | Cabinet thickness | < 170 mm |
| 8. | Bracket of cabinet | Easy to install onto the LED cabinet and uninstall . |
| 9. | Brightness | ≥ 6500 nits |
| 10. | Colors | 16.7million |
| 11. | Viewing angle | Horizontal ≥120°, Vertical : ≥ 45° |
| 12. | Viewing distance | 10m -300m |
| 13. | Soft Rubber Mask | To protect player and LED display itself . |
| 14. | Scan frequency | ≥600 Hz
There will be one receive card in each cabinet ,so that the LED display won't sparked .Also it is very easy to move and connetct |
| 15. | Video Frame Rate | ≥150 fps |
| 16. | Color temperature | 6500°K to 9500°K adjustable |
| 17. | Control method | Controlled by PC, synchronous display |
| 18. | Life span( half brightness) | ≥100,000 hours |
| 19. | Weight | 70Kg /sqm |
| 20. | IP rate | IP65 ( front side and rear side) |
| 21. | Average power consumption | 400W/sqm |
| 22. | Peak power consumption | 1300W/sqm |
| 23. | Input voltage | AC220V/50Hz ±10% or AC110V/60Hz ±10% or AC380V/60Hz ±10% |
| 24. | Operating Environment | Temperature:-20+60 Humidity:10%95%RH |
| 25. | Operating system | Windows 98/2000/ME/XP |
| 26. | Type of video signal | S-video, composite video ,RGB ,VGA ,DVI |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
