Q4 4 moving head mini led beam diso light
Model: UP-TQ4;
Input voltage: 90-220V AC, 50/60HZ
Light source: -4pcs 10w white led chip
- Average lifetime: 60, 000 h
Power: 80~90W;
Channel: 9/28 channels;
Strobe: 1~25 times/second;
Movement: Pan=540° +fine Tilt=270° +fine;
Beam angle: 8° ;
Dimmer: 0~100% linear dimmer;
Waterproof rate: IP20;
Color: Pure white;
Control: DMX512, Auto-run, Sound control, Master-slave;
Net weight: 12 Kg;
Gross weight: 14KG;
Packing size: 1030*90*250mm;
Packing: Carton/Double fly case;
Application: Disco, DJ, club, party, stage and so on
|
Channel |
Function |
Value |
|
CH1 |
Pan 1 |
0-255 |
|
CH2 |
Pan 1 fine |
0-255 |
|
CH3 |
Tilt 1 |
0-255 |
|
CH4 |
Tilt 1 fine |
0-255 |
|
CH5 |
Speed |
0-255 |
|
CH6 |
Dimmer 1 |
0-255 |
|
CH7 |
Strobe 1 |
0-255 |
|
CH8 |
Pan 2 |
0-255 |
|
CH9 |
Pan 2 fine |
0-255 |
|
CH10 |
Tilt 2 |
0-255 |
|
CH11 |
Tilt 2 fine |
0-255 |
|
CH12 |
Speed |
0-255 |
|
CH13 |
Dimmer 2 |
0-255 |
|
CH14 |
Strobe 2 |
0-255 |
|
CH15 |
Pan 3 |
0-255 |
|
CH16 |
Pan 3 fine |
0-255 |
|
CH17 |
Tilt 3 |
0-255 |
|
CH18 |
Tilt 3 fine |
0-255 |
|
CH19 |
Speed |
0-255 |
|
CH20 |
Dimmer 3 |
0-255 |
|
CH21 |
Strobe 3 |
0-255 |
|
CH22 |
Pan 4 |
0-255 |
|
CH23 |
Pan 4 fine |
0-255 |
|
CH24 |
Tilt 4 |
0-255 |
|
CH25 |
Tilt 4 fine |
0-255 |
|
CH26 |
Speed |
0-255 |
|
CH27 |
Dimmer 4 |
0-255 |
|
CH28 |
Strobe 4 |
0-255 |
