P6 Highlights
1, Ruggedized design
The special slim and light weight design of the new P6 cabinets guarantees you fast installation and transportation. The selection of the robust components ensure the life time of the panels, especially when used during road shows or in a harsh working environment.
2, Fast Installation
The special design makes flying the panels fast easy and save. The panels are equipment with rigging points and rig-locks at the top and bottom of the cabinet, for quick installation of the display. Stash up to 6 sq. M in 1 single flight case, it will save you time, manpower and transportation costs.
3, Consistent uniformity
Advanced brightness and color calibration offers you the highest picture uniformity and extended color balance. The radiant calibration camera ensures color uniformity for a panel life time. with it's contrast ratio of over 3000: 1 you will attract your audience whether they are nearby or at a distance.
4, High Refresh Rate
with its refresh rate of up to 2.000 Hz the new P6 indoor rental panels are suitable for all indoor and studio applications. There will be no interference with any TV cameras in the studio or show setting.
5, Enhanced Heat Sync
with its new revolutionary heat sync design, the P6 display ensures improved heat radiation. The cool ribs on all four sides of the back of the panel make sure your P6 rental panel has the perfect heat sync at any brightness and in any application. The new P6 is one of the first cabinets without forced ventilation. It makes it the most silent panel in its class.
6, 5-year parts planning
The mass production of P6 cabinets is starting now. with its advanced Radiant Image Calibration technology, the data of brightness and color are automatically saved in each module. Spare parts and modules with relevant data are always available during the 5 years warranty.
Furthermore English spoken 24/7 help and service desk is available for trouble shooting and technical support through phone and Internet on site to help wherever and whenever it is.
7, Brilliant Colors, Breathtaking Grayscales
with extra grey scale and 16-bit processing, this P6 display delivers the finest image quality. Featurering 140 degree horizontal and 140 degree vertical viewing angle allows you long-distance off-axis viewing, perfect for any staging and entertainment venue.
|
|
MODEL |
OTL6 |
|
LAMP |
LED Type |
3in1 SMD (4040) |
|
BOARD |
Pixel config. |
1R1G1B |
|
LED Driving Method |
1/4 Dynamic Scan |
|
Pixels |
48x48 |
|
Pixel Pitch |
6mm |
|
LED Board Size |
288mm x 288mm |
|
MODULE |
LED Boards |
2x2 |
|
Pixels |
96x96 |
|
Module Area |
0.33sq.m |
|
Module Size |
576mm x 576mm x 80mm |
|
Net. Weight |
12.5kg |
|
Power |
AC 220/110 47~63Hz |
|
Water Proof |
IP65 |
|
Serviceability |
Rear service |
|
DISPLAY |
Max. Power Consumption |
<=860W/sqm |
|
Avg. Power Consumption |
<=301W/sqm |
|
Max. Current |
4.13A |
|
Hor. Viewing Angle (min50% brightness) |
120 degree |
|
Vert. Viewing Angle (min50% brightness) |
120 degree |
|
Brightness |
>=6,500cd/sqm |
|
Pixel Density |
27.777/sqm |
|
Power Factor |
>0.9 |
|
Certification |
UL,CE,ETL,ROSH,CCC |
|
Contrast Ratio |
2,000:1 |
|
Operation Temperature |
-20C ~ 60C |
|
Operation Humidity |
20%~90% |
|
Lifetime (50% brightness) |
100,000 hrs |
|
Processing |
1/4bit |
|
Colors |
281 trillion |
|
Refresh Rate |
>=4,000Hz |
|
Frame Rate |
60fps |
|
Brightness Level |
Manual 100lv, Auto 16lv |
