LED Display Screen LED Sign LED Curtain Indoor LED Display
Full Color Indoor LED Sign
Full Color Indoor LED Display
Features of the Our LED Display:
*Quick assembly model, 2 persons are able to assemble 20sqm within one hour
*Light weight, for indoor application, only 35-38kg/sqm, for outdoor application, only 45-55kg/sqm
*Weatherproof to IP65 standards
*High resolution images
*Easily configured for various size and aspect ratios
*Wide viewing angle
*Brightness is adjustable depends on environment
*Compatible with inputs: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA
Other features:
1. CE. RoHS. FCC. C-Tick authorized;
2. ISO9001: 2008 QC system;
3.100.000 hours life span;
4. Water proof. Dust proof;
5. AC 85V to 265V power input;
6. Video. Flash. Animation. Graphic. Text available;
7. PC controlled in real time;
8. Installation structure drawing offered FOC;
9. Easy for installation;
10.2 years warranty offered;
11.1% spare parts offered FOC;
12. Training in our factory offered FOC;
13. On-line remote service is available;
14. EXW. FOB. CIF accepted;
15. Factory visiting and inspecting is welcome;
16. OEM service offered;
17. The monthly production capacity 2000 Sq. M
18. Models available:
P4mm. P5mm. P6mm. P7.625mm. P10mm. Etc. For indoor use;
P10mm. P12mm. P16mm. P20mm. P25mm. Etc. For outdoor use.
|
Full Color SMD3528 Indoor Module |
|
Item |
Unit |
Parameter |
|
Pixel Pitch |
mm |
5.00 (Optional) |
|
Resolution of Module |
dots |
32× 32 |
|
Module Size |
mm |
160× 160 |
|
Module Weight |
kg |
0.2 |
|
Pixel Configuration |
SMD3528 1R1G1B |
|
Chip Brand of LEDs |
Silan/Epistar/Cree/Nichia |
|
Pixel Density |
dots/sqm |
40, 000 |
|
Brightness (White Balance) |
nits(cd/sq. m) |
≥ 2000 |
|
Red Wavelength |
nm |
620-625 |
|
Green Wavelength |
nm |
520-525 |
|
Blue Wavelength |
nm |
470-475 |
|
Scan Mode |
1/8 Scan or 1/16 Scan optional |
|
Viewing Distance |
M |
3--35 |
|
Best View Distance |
M |
5--15 |
|
Viewing Angle-Horizontal |
deg. |
120 |
|
Viewing Angle-Vertical |
deg. |
120 |
|
Module Maximum Power |
W |
25 |
|
Max. Power Consumption |
W/sq. m |
1, 000 |
|
Avg. Power Consumption |
W/sq. m |
300 |
|
Working Voltage |
5V 40A |
|
Power Supply |
AC 110/220V |
|
Refresh Rate |
Hz/S |
3, 000 |
|
Frame Rate |
Hz/S |
≥ 60 |
|
Gray Scale |
4096 grades gray |
|
Display Color |
256*256*256 |
|
Display Function |
Text, news, advertising, flash, animation |
|
Input Signal |
RF, S-Video, RGB, RGBHV, YUV, YC, SDI, HD-SDI, DVI, UXGA, COMPOSITION, etc. |
|
Luminance Degradation |
Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25. |
|
Defective Dot Rate |
0.0001 |
|
Life Span |
hours |
100, 000 |
|
MTBF |
hours |
5, 000 |
|
Storage Temperature |
|
-35 -- +80 |
|
Working Temperature |
|
-20 -- +60 |
|
Working Humidity |
10-90RH |
|
Control System |
Synchronization or Asynchronization |
|
Quality Certificate |
ISO9001: 2008, SGS, BUREAU VERITAS |
|
Warrenty |
2 Years |
|
Working Environment |
Indoor |
|
Note: The above parameter is just for reference. Changes can be made according to customers' requirements. |
Channel Cailiang (Zhangzhou) Optoelectronic Co., Ltd. is one of the biggest LED manufacture in China. Our factory have 30 PCS production line for Outdoor DIP Modules, 5 PCS line for Indoor SMD products and more than 1, 500 skilled workers. Our R&D team are comprised of a crew of 10% of total staff and most of engineers have more than 5 years experience in LED industry, which great support our new products developing or customized products according to customers' requests.
Our Main Business is Produce various LED Display Module and LED Display Panel for Customers' assemble. It' s avaliable supply all the components for assemble LED Display or LED Message Signs. Besides, we focus on offering whole proposal for LED Display Projects and Solutions. Not only for regualr type, we have continuously developed several Profiled Screens and achieved some proud success in developing Traffic Wireless Solution Display Screens.
In order to design and develop higher quality products, our R&D team always tries best to meet the US&Euro-standards for Electronic products, as well as to fulfill the special requirements from customers. Our products have been approved the German TUV- EMC Certification and Euro EN12966 Certification, and we have also achieved ISO9001: 2000, CCC, CE, FCC, RoHS Certifications.
with perfect designed products, integrated solution including both hardware and software, and superior product and service guarantee, Cailiang has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 50 countries and regions all over the world, such as in the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, Italy, etc.
We value the power of cooperative team work, we take "Quality & Honesty" as our belief, and "Being the Largest Global Supplier of LED display Solution" as our goal.
"Channel Cailiang" Sincererly Invite your participation!
