1 Ruggedized design
The special slim and light weight design of the new 4mm pixel pitch cabinets guarantees you fast installation and transportation. The selection of the robust components ensure the life time of the panels, especially when used during road shows or in a harsh working environment.
2 Fast Installation
The special design makes flying the panels fast easy and save. The panels are equipment with rigging points and rig-locks at the top and bottom of the cabinet, for quick installation of the display. Stash up to 6 sq. M in 1 single flight case, it will save you time, manpower and transportation costs.
3 Consistent uniformity
Advanced brightness and color calibration offers you the highest picture uniformity and extended color balance. The radiant calibration camera ensures color uniformity for a panel life time. With it's contrast ratio of over 3000: 1 you will attract your audience whether they are nearby or at a distance.
4 High Refresh Rate
With its refresh rate of up to 2.000 Hz the new 4mm indoor rental panels are suitable for all indoor and studio applications. There will be no interference with any TV cameras in the studio or show setting.
5, Enhanced Heat Sync
With its new revolutionary heat sync design, the 4mm display ensures improved heat radiation. The cool ribs on all four sides of the back of the panel make sure your 4mm rental panel has the perfect heat sync at any brightness and in any application. The new 4mm is one of the first cabinets without forced ventilation. It makes it the most silent panel in its class.
5, 5-year parts planning
The mass production of 4mm cabinets is starting now. With its advanced Radiant Image Calibration technology, the data of brightness and color are automatically saved in each module. Spare parts and modules with relevant data are always available during the 5 years warranty.
7 Brilliant Colors, Breathtaking Grayscales
With extra grey scale and 16-bit processing, this 4mm display delivers the finest image quality. Featurering 140 degree horizontal and 140 degree vertical viewing angle allows you long-distance off-axis viewing, perfect for any staging and entertainment venue.
|
Resolution |
4 mm |
|
LAMP |
LED Type |
SMD 3-in-1 |
|
BOARD |
Pixel configuration |
1R1G1B |
|
LED driving method |
1/16 dynamic scan |
|
Pixels |
64 |
* |
32 |
(W*H) |
|
Pixel pitch |
4 |
mm |
|
Led board size |
256 |
mm |
* |
128 |
mm |
* |
5 |
mm |
|
(W*H*D) |
|
MODULE |
Led boards |
2 |
* |
4 |
(W*H) |
|
Pixels |
128 |
* |
128 |
(W*H) |
|
Module area |
0.26 |
m2 |
|
Module size |
512 |
mm |
|
* |
512 |
mm |
|
* |
100 |
mm |
|
(W*H*D) |
|
Net weight |
12 |
kg |
(aluminum) |
/ |
23 |
kg |
(ferrum) |
|
Power |
AC220/110 ± 10%, 47~63Hz |
|
Water proof |
N/A |
|
Serviceability |
Rear service |
|
DISPLAY |
Max. power consumption |
≤ |
|
980 |
W/m2 |
|
Avg. power consumption |
≤ |
|
343 |
W/m2 |
|
Max. current (208V 60Hz) |
≤ |
|
5.24 |
A/m2 |
|
Hor. viewing angle(min 50% brightness) |
120° |
|
Vert. viewing angle(min 50% brightness) |
120° |
|
Brightness |
≥ 1200 cd/m2 |
|
Pixel density |
62500 |
/m2 |
|
Power factor |
> 0.9 |
|
Certifications |
UL, CE, ETL, ROSH, CCC |
|
Contrast ratio |
2000: 1 |
|
Operating temperature |
-20º C to +60º C |
|
Operating humidity |
20% to 90% |
|
Lifetime (50% brightness) |
100, 000 hours |
|
Processing |
16 bit |
|
Colors |
687 billion |
|
Refresh rate |
≥ 300 Hz |
|
Frame rate |
60 fps |
|
Brightness level |
Manual 100 levels, automatically 16 levels. |
