Resolution2.5 mm LAMPLED SMD 3 in 1
BOARDPixel configuration1R1G1B
LED driving method1/32 dynamic scan
Pixels96*64(W*H)
Pixel pitch2.5mm
Led board size240mm*160mm*10mm(W*H*D)
MODULELed boards2*3(W*H)
Pixels192*192(W*H)
Module area0.23m2
Module size480mm*480mm *90mm(W*H*D)
Net weight11kgalluminun
PowerAC220/110 ± 10%, 47~63Hz
Water proofN/A
ServiceabilityRear service
DISPLAYMax. power consumptionR≤1080W/m2
Avg. power consumption≤378W/m2
Max. current (208V 60Hz)≤5.19A/m2
Hor. viewing angle(min 50% brightness)120°
Vert. viewing angle(min 50% brightness)120°
Brightness≥1200 cd/m2
Pixel density160000/m2
Power factor>0.9
Contrast ratio2000:1
Operating temperature -20ºC to +50ºC
Operating humidity20% to 90%
Lifetime (50% brightness)100,000 hours
Processing16 bit
Colors281 trillion
Refresh rate1200 Hz
Frame rate60 fps
Brightness levelManual 100 levels,automatically 16 levels.
*Features and specifications are subject to change without prior notice.
Welcome to Retop LED Display-your one stop solution provider for all things LED related. As a renowned manufacturer in the growing Chinese industry, we have completed more than 10, 000 worldwide installation projects over the span of nearly 2 decades. In the pursuit of excellence, we succeeded in breaking numerous industry records. Retop is widely acknowledged as a world-leading designer and producer of high quality LED screens. Our target markets include sports, advertising, rental & stage, etc. To learn more, please ask us about our fully featured customization options!
Through vertical integration Retop is able to optimize the industrial chain. Our scope of expertise ranges from LED wafers & chips to LED control systems, LED lamps, LED encapsulation, and LED displays.
Retop is a publicly listed LED display manufacturer. We are fully integrated with our parent company Elec-Tech. Headquartered in Wuhu city, our facilities cover an area of 120, 000 square meters. We proudly declare our production base to be the largest in mainland China. Our company strives to deliver stunning LED solutions that can satisfy all customer requirements. Standardization and flexible production allow us to offer competitive prices for a wide range of high quality products. Our valued clients can enjoy the benefits of attentive service and prompt delivery. For the past 9 years, we have made steady progress in the
Development of overseas markets. Our success can largely be attributed to an outstanding reputation and a diverse client base.
Ingenuity and perseverance have firmly established us as pioneers in the LED display industry. Our company is dedicated to the research and development of LED related technologies. Retop products are approved by CE, UL, CCC, EMC, ETL, and FLL. We are fully certified by ISO standards.
