G10/12 is a light, thin and transparent products that very suitable for lighting rental and large square application. Jointed correctly, easy to install and dismount, simple constitution with the performance of secure and durable. The size unit size is 1000*500*54 ( L*W*H), while the weight is only 7.5kg, with high transparency. G10/12 with the performance of light, thin and transparent are very suitable for application on entertainment areas, such as TV stage and clubs. It could be change colors and produce images. The display image are pretty clear, true and magic. G10/12 is the best choice for creative designing company to produce large square image.
Advantages:
Light, suitable for flow shows, convenient in transporting and jointing.
Nice appearance and secure.
Jointed correctly, could be dismounted by one person without tool
High transparency. Light, air and frost could easily cross through it.
Humanized operating interface with breakdown indicator lights.
High debugging brightness with 500-2000nit and no damage to gray scale, matched well with the debugging technology with nice image.
Specification:
|
Item |
|
G10 |
|
G12 |
|
Pixel Pitch |
|
10.416mm |
|
12.5mm |
|
Pixel Configuration |
|
RGB 3in1 SMD3528 |
|
RGB 3in1 SMD3528 |
|
Pixel Density/sqm |
|
9216 |
|
6400 |
|
Resolution |
|
48*96 |
|
40*80 |
|
Max.Power Consumption |
|
200W/panel |
|
150W/panel |
|
Ave.Power Consumpution |
|
80W/panel |
|
60W/panel |
|
Weight |
|
9.5KG |
|
9KG |
|
Viewing Distance |
|
≥10m |
|
≥12m |
|
Brightess |
|
900-1500nit |
|
Panel Size |
|
500mm×1000mm×54mm |
|
Viewing Angle(H/V) |
|
140°/140° |
|
Gray Scale |
|
14bit |
|
Refesh Rate |
|
1920Hz |
|
Color Depth |
|
68.7billion |
|
Gamma |
|
–5.0~5.0 |
|
Protection Level |
|
IP43 |
|
Control System |
|
Synchronous display with control PC by DVI |
|
Signal Input |
|
Composite,S-vide, Component,VGA,DVI,HDMI,HD-SDI |
|
Power Supply |
|
AC90~260V 50/60Hz |
|
Working Environment |
|
Temperature-10°C~50°C,Humidity 10~90%RH |
|
Lifetime |
|
>50000hours |
|
Certififate |
|
CE |
