Overview
1) This whole screen use aluminum alloy, the surface is very flat and the whole screen is seamless stitching.
2) Dust proof, IP 43, it can be customized to IP65.
3) Humanized operating interface with breakdown indicator lightings. Very easy for maintenance.
4) Large viewing angle up to 140 horizontally and vertically, the image won't be out of shape and audience will get vivid video effect within any position of the viewing range.
5) It Could be exact connected and easy to install and dismount.
Item Name
|
Tn6 |
Pixel Pitch
|
6mm |
LED configuration
|
SMD3528 1R1G1B 3 in 1 |
Pixel density
|
25600 dots/m2 |
Pixel Resolution
|
80 × 80 dot |
Cabinet Size
|
500x500x62 mm |
Shortest viewing distance
|
6 m |
Weight / Module
|
7.5 KG |
Brightness
|
1500 CD/m2 |
Viewing Angle (H/V)
|
140°/140° |
Gray Scale
|
12 bit |
Power Consumption
|
average 80W/ PCS, max 150W/ PCS |
Refresh rate
|
>1800HZ |
Protection Level
|
IP43 / IP65 ( Optional ) |
View Distance
|
≥6m |
SHENZHEN VTEAM Co., Ltd. is a professional ODM LED Screen manufacturer in Shenzhen, China, specialized in creative indoor and outdoor LED screen with experienced R&D team who has been working in LED display field for more than 8 years.
VTEAM screen is popular with the features of light weight, ultra-thin cabinet, transparent structures and widely-used in the application of TV Station, studios, auto shows, music concerts, clubs, discos, building facade, outdoor decorative lighting projects, exhibitions, celebrations etc.
As one of leaders of LED Screen suppliers in China, All products carry CE RoHS certification, with perfect designed products, customized solution, superior product and service guarantee, VTEAM has been highly praised by domestic and overseas customers, we have been shipping qualified products and services to more than 100 countries and regions all over the world, such as in the USA, Russia, Germany, Sweden, France, Netherland, Spain, Canada, Brazil, Mexico etc. The most notable of those successful projects is that we have done the creative "Giant Football" for the opening&closing ceremony of 2014 Brazil FIFA WORLD CUP!
VTEAM Mission: To create value and profit for customers!
VTEAM Vision: Being creative concept pioneer!
