1. High brightness and adjustable the need of the changing requirement of customer in environment;
2. Having good lightening accordance and no mosaic;
3. Using virtual pixels, better viewing effect for both text & graphic and video;
4. Having larger viewing angle: Horizontal angle 160 degree/elevation angle 160 degree. Getting vivid effect within any position of the viewing range;
5. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
CreateLED's conventional screens(pH-12) are managed by advanced and professional for video screen drive and control systems. They are capable of visualizing more than 281 trillions of colors with a resolution of 16 bit continuously per color. With pixel-sharing technology. CreateLED displays always deliver to all of our customers with excitement!
The basic protection of video screen guarantees a better and longer lifetime. CreateLED has focused on developing this feature and can manufacture all the screens to a protection level of IP65 on the front side, and IP54 on the rear side with iron with cotton filter, which completely isolates the screens from rain and dust. Besides all cabinets with 1000mmx100Omm, which are enable to fit customers ideal screen size.
LED display, LED display screen, outdoor LED display, LED display panel, advertising LED display, advertising billboard are available.
|
PH-12 |
|
|
Pixel Pitch |
12mm |
|
Unit Size |
960mmx768mm |
|
LED Type |
SMD 3-IN-1 |
|
Pixel / Unit |
80x64 |
|
Unit Weight |
45kg |
|
Viewing Angle |
H160° V160° |
|
Application |
Storage-40~60° C, Working-20~50° C |
|
Protection Level |
IP65/IP54 |
|
Power Consumption |
800W/panel Max |
|
|
320W/Panel Ave. |
|
Driving |
1/4 Scan |
|
Frame Refresh |
≥ 60Hz |
|
Data Refresh Rate |
600~2, 000Hz |
|
Processing |
16bit |
|
Max Brightness |
4000-5500nits |
|
Power Supply |
AC90-240V, 50~60Hz |
|
MTBF |
≥ 1, 000 Hours |
|
Life Span |
≥ 50, 000 Hours |
|
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
