Fullcolor high brightness Outdoor LED displays(AirULTRA-10).
CreaetLED AirULTRA-10, which offers excellent contrast and image quality, is a true waterproof high-resolution outdoor SMD LED display which can be used for both rental and staging industry, whether indoor or outdoor. Thanks to its modular standard design and low weight, the AirULTRA-10 is simple to install and service.
To work with the waterproof SMD system instead of using the current standard paralyene coating which is susceptible to UV "yellowing" effect, CreateLED AirULTRA-10, is the truly waterproof LED display panel, combining ultra-lightweight design with remarkable high-performance, this LED display will be the ideal solution for outdoor use with high performance needed.
Furthermore, it's an ideal solution for applications which the weight loading limited, and the maximum creative freedom is needed, the most important is which the brightness and waterproof is needed.
Key Benefits
1. Innovative waterproof surface mounted technology allows intense high resolution images.
2. Ultra-High brightness of 5, 000 nits, Sunlight readable.
3. IP Rating: IP65.
4. High resolution display: 10.4mm pixel pitch, 48 X 48 dots.
5. Extremely close viewing distances and wider viewing angles of 160 degree.
6. Light output of 5, 000 nits, offering bright display.
7. Silent operation, little heat generated (no fans).
8. Standard panel design makes stocking, transportation, construction, spare parts and maintenance easy and simple.
9. Lightweight and seamless precision extruded aluminum section structure.
10. Real white, brilliant color, breathtaking grayscale
Ideal For:
Events, Concert Touring, CasinoPub & Club, Theatre and Arts, TV Shows, Car Shows, Billboard
|
AirULTRA-10 |
Outdoor LED displays |
|
Pixel Pitch |
10.4mm |
|
LED Type |
3-in-1 SMD |
|
Brightness |
4, 500nits-5, 000nits |
|
Viewing Angle |
H: 160 degree |
|
V: 100 degree |
|
Contrast Ratio |
4000: 1 |
|
Pixel Density |
9.216/sqm |
|
1, 524/sqf |
|
4, 096/panel; 6, 144/panel |
|
Module Size |
250mm x 250mm |
|
Module Resolution |
24 x 24 |
|
Panel Size(WxHxD) |
500mmx500mmx65mm |
|
Panel Resolution |
48 x 48 |
|
Weight |
10kg/panel |
|
Power Consumption |
300W/Panel Max |
|
120W/Panel Ave |
|
Processing |
16 bit/color |
|
Refresh Rate |
600-1,200Hz |
|
Drive Method |
1/2 Scan Method |
|
Environment |
Outdoor or indoor use |
|
Max Stacking |
20 panels |
|
Max Hanging |
20 panels |
|
Servicing |
Front & Back |
|
Panel Material |
Precision Extruded Aluminum Section |
|
Source Compatibility (with Processor) |
VGA(RGBHV), DVI, HDMI, SDI(HDSDI) |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
