Outdoor Full Color High-Resolution LED Display (P7)
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB |
| Min Order: |
1/Piece |
| Pay Type: |
T/T |
AirULTRA-7 Description
CreaetLED AirULTRA-7, which offers excellent contrast and image quality, is a true waterproof high-resolution outdoor SMD LED display which can be used for both rental and staging industry, whether indoor or outdoor. Thanks to its modular standard design and low weight, the AirULTRA-7 is simple to install and service.
To work with the waterproof SMD system instead of using the current standard paralyene coating which is susceptible to UV "yellowing" effect, CreateLED AirULTRA-7, is the truly waterproof LED display panel, combining ultra-lightweight design with remarkable high-performance, this LED display will be the ideal solution for outdoor use with high performance needed.
Furthermore, it's an ideal solution for applications which the weight loading limited, and the maximum creative freedom is needed, the most important is which the brightness and waterproof is needed.
Key Benefits
1. Innovative waterproof surface mounted technology allows intense high resolution images.
2. Ultra-High brightness of 5, 000 nits, Sunlight readable.
3. IP Rating: IP65.
4. High resolution display: 7.8mm pixel pitch, 64 X 64 dots.
5. Extremely close viewing distances and wider viewing angles of 160 degree.
6. Light output of 5, 000 nits, offering bright display.
7. Silent operation, little heat generated (no fans).
8. Standard panel design makes stocking, transportation, construction, spare parts and maintenance easy and simple.
9. Lightweight and seamless precision extruded aluminum section structure.
10. Real white, brilliant color, breathtaking grayscale
Ideal For: Events
Concert TouringCasinoPub & ClubTheatre and ArtsTV ShowsCar ShowsBillboard
AirULTRA-7 Specifications
Mechanical
Module size: 250mm X 250mm
Panel size: 500mm X 500mm X 82mm
Panel weight: 10kg
Weight per m2: 40kg
Support frame in aluminum
Video Display
LED type: Blackbody SMD 3 in 1
Resolution: 64 X 64 pixel/panel
Pixel pitch: 7.8mm
LED population: 16, 384 LED/
Brightness: 5, 000 Nits
Drive method: 1/2 scan method
Lifetime(50% brightness): 100, 000 h
Colors: 281 trillion
Gray scale: 16 bit
Refresh rate: 600~2, 000 Hz
Viewing angle: H: 160° , V: 100°
Dead Pixel Ratio: <0.0003
Electrical
Power supply: AC 220-240 V, 50/60 Hz
Power consumption: Avg 120 W/panel
MTBF ≥ 1, 000 H
Ambience working temperature: -20~55
Ambience humidity: 85% at 25, 65% at 40
Control System
Sender Box input: USB connector
Sender Box output: RJ45 connector
Connection between PC and Sender Box: USB cable
Supported video input: DVI/HDMI/SDI
Software functions: Display configuration, intensity adjustment, color calibration, content management, and system settings.
| Prod Model: |
Outdoor full color led display |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Scanning Mode: |
1/16 Scan |
| Certification: |
ETL |
| Pixel Density: |
10000 dot / m² |
| Average Power Consumption: |
220W / m² |
| Pixel Pitch: |
7.8mm |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
