Moving Head 36*10W RGBW LED Wash Stage Light
Input voltage: AC100~240V, 50~60Hz;
Rated Power: 400W;
LED lamp: 10W high power LED with long life 80000-100000 hours, high luminous efficiency, no radiation and low power consumption etc;
LED Qty: 36 LEDS with Red, Green, Blue, White 4 in 1;
LED Lamp powr supply: Adopt power factor correction PFC switching power supply, PF> 0.99, the efficiency of up to 90%, it's real green and environmental protection;
LED drive mode: Adopt static constant current drive mode with high precision and non-flicker (400HZ);
Control Mode: DMX512 signal 3-pins connection control, master-salve control or sound control with self-programming mode, self-running mode, extral control mode;
Channel: 12ch, 16ch two channel modes;
Color: Red, Green, Blue, White 4 in 1 full colors which is the most favorite color mixing way for lighting technician;
Lens: High optical transmission acrylic lens;
Zoom angle: 10° - 60° (standard angle);
Dimmer: 0~100% linear dimmer;
Strobe: Multi-function strobe effects from 1 to 25 times per second with the soft light function;
Material: Aluminum alloy plus plastic;
Maximum working terperature: 45° C
Maximum surface temperature: 60 ° C
Application: Lighting for TV studio, theater, opera house, auditorium, stage, T-stage, concerts, and vocal concert,
DJ effect, disco effect, club effect, party effect etc;
Package size: 425× 295× 395mm
Gross weight: 9.5kg
|
12 Channels |
16 Channels |
Function |
|
CH 1 |
CH 1 |
Dimming |
|
CH 2 |
CH 2 |
RED |
|
CH 3 |
CH 3 |
GREEN |
|
CH 4 |
CH 4 |
BLUE |
|
CH 5 |
CH 5 |
WHITE |
|
CH 6 |
CH 6 |
User-defined lighting |
|
CH 7 |
CH 7 |
Pan scanning |
|
CH 8 |
CH 8 |
Tilt scanning |
|
CH 9 |
CH 9 |
Pan scanning fine |
|
CH 10 |
CH 10 |
Tilt scanning fine |
|
CH 11 |
CH 11 |
Scanning speed |
|
CH 12 |
CH 12 |
Zooming |
|
|
CH 13 |
Strobe |
|
|
CH 14 |
RGBW marco function |
|
|
CH 15 |
Auto speed adjustment |
|
|
CH 16 |
ID code |
