MODEL: LED 2009: 36*1W/36*3W (12Red/ 12Green/ 12Blue)/(9Red/ 9Green/ 9Blue/ 9White(or Amber)
MODEL: LED 2009A: 48*1W/48*3W (16Red/16Green/ 16Blue)(12 Red/ 12Green/ 12Blue/ 12White(or Amber)
MODEL: LED 2009B: 72*1W (24Red/ 24Green/ 24Blue)/(18Red/ 18Green/ 18Blue/ 18White(or Amber)
MODEL: LED 2009C: 96*1W (32Red/ 32Green/ 32Blue)/(24Red/ 24Green/ 24Blue/ 24White(or Amber)
MODEL: LED 2009D 144*1W (48Red/ 48Green/ 48Blue)/(36Red/ 36Green/ 36Blue/ 36White(or Amber)
Control signal: DMX512
Power consumption: 45W/55W/155W/80W/105W/155W
Protection rating: IP 65
1) Input voltage: AC 90-130V/280V-240V/50-60Hz, auto change
2) Power: 140W
3) LED size: 1W/3W
4) DMX Channels: 6CH/3CH, 7CH/4CH
Compatibility:
1. Color Range 16.7 million additive RGB colors; Continuously variable intensity (256× 256× 256=16777216)
2. Dimming 0-100%with regulated constant color control
3. Strobe: 10 Flashed per second (any color)
4. Function: It is max mix color, color change, colors gradual change, flash, speed/luminance the adjustable, sound activity and Save function.
5.6channel Mode and 3channel Mode would change each other in every light
6. DMX Channels-6CH Mode:
CH 1 General Dimmer (1-255, from dart to light)
CH 2 Red (1-255, Dimmer, from dart to light)
CH 3 Green (1-255, Dimmer, from dart to light)
CH 4 Blue (1-255, Dimmer, from dart to light)
CH 5 Strobe & Color change &color gradual change's open
CH 6 Strobe & Color change & color gradual change's speed adjustment (1-255, Speed adjustment, from slow to fast)
7. DMX Channels-3CH Mode:
CH 1 Red (1-255, Dimmer, from dart to light)
CH 2 Green (1-255, Dimmer, from dart to light)
CH 3 Blue (1-255, Dimmer, from dart to light)
MS Lighting is a professional stage lighting manufactory in China, Our products are LED Light, moving head light(spot/wash, 150W-1200W), DMX scannner, effect lights, disco lights, laser etc.
Our products are very popular by professional from all walks of life; It makes the perfect stage effect with the others stage lighting products. We have excellent quality products and the best after-sales service.
The aim of our work is your satisfaction
This is the good factory that your first choice.
