Main adventage:
1. Long service life, service life is 50000 hours under nominal working conditions, and only 5% decrease in the first 1000 working hours;
2. Bright colored, color saturation can be reached at more than 90% to produce more brilliant light effects;
3. High efficiency and low power consumption. There is no color filter loss, being efficient at electro-optic transfer;
4. RGB color mixing with or without DMX control;
5. Environmental protected, since there is no ultraviolet radiation and infrared ray in the spectrum, it is low at heat emission and radiation;
6. with a build-in stand alone function and master / slave mode available;
7. Current protection to PCB panel and over-heat protection;
8. 64 sub-ID codes addressing panel available in one DMX address.
Specifications:
Power Supply: AC220± 10% 50Hz (AC110± 10% 60Hz available)
Power Consumption: 80W max
Light Source: Red: 28x1w, Green: 28x1w, Blue: 24x1w
Beam Angle: 45° (25. )
Illumination Intensity: 12540Lx@1m (25° )
Control Channels: 5/7/ 11
Control Signal: DMX512, Auto Mode, Master/Slave Mode
Input Signal: XLR 3-pin (In & Out)
Combined Safety Design: Patent technology
Working Temperature: -20° C~40° C
Protection Grade: IP65
Dimension: 540mm× 215mm× 305mm
Net Weight: 5.2 kg
