Source chip: High brightness LED (made in Taiwan GUANGJIA, Xiamen SANAN, Taiwan JINGYUAN with original packaging)
Source power: 6 W, 8W, 12W, 15W, 18W (optional)
Power efficiency: 85%
Electricity level: II
LED quantity: SMD (optional)
Wavelength: R(620-630nm), G(520-530nm), B(465-475nm)
Lighting Angle: 120° , 160° (optional)
IP: IP65
Control configuration: Internal controlled by SCM, adopting signal wire to realize synchronous control between luminaires; External control by 485 signal, full-automatic and intelligent controlled by PC.
Color range: 16777216(24Bit) additive RGB colors; 16700, 000 RGB complex true colors; Realize synchronization, chase, moving water, gradual change etc.
Input voltage: DC12-24V
Luminaire color: Silver grey, transparent and semitransparent etc.
Wire: Four cores wire and two cores wire(Temperature resistant, cold-resistant, aging-resistant and uvioresistant UL-94V0)
Material: Aviation aluminum with good quality (aluminiumtanker) + tempering glass
Working temp: -30° C-50° C
LED lifespan: 50000hrs
Operating environment temp: -30-60° C
Operating environment humidity: 60%-99%RH
|
Product Series Specs Form |
|
|
|
|
|
|
|
|
|
No. |
Type |
Name |
Dimension |
Voltage |
Power |
Color |
LED |
Power of 1 LED |
|
1 |
MY-XQ005022Q-02 |
Wash wall light |
φ 20 |
DC: 5V |
22 |
True color |
32 |
0.6 |
|
2 |
MY-XQ024012Q-02 |
Wash wall light |
φ 20 |
DC: 24V |
16 |
Rainbow colors |
60 |
0.2 |
|
3 |
MY-XQ024012R-02 |
Wash wall light |
φ 20 |
DC: 24V |
16 |
Red |
60 |
0.2 |
|
4 |
MY-XQ024012G-02 |
Wash wall light |
φ 20 |
DC: 24V |
16 |
Green |
60 |
0.2 |
|
5 |
MY-XQ024012B-02 |
Wash wall light |
φ 20 |
DC: 24V |
16 |
Blue |
60 |
0.2 |
|
6 |
MY-XQ024012Y-02 |
Wash wall light |
φ 20 |
DC: 24V |
16 |
Yellow |
60 |
0.2 |
|
7 |
MY-XQ024012Q-02 |
Wash wall light |
φ 20 |
DC: 24V |
12 |
White |
60 |
0.2 |
