Source chip: High brightness LED (imported from USA LUMILEDS/CREE, Germany OSRAM, Taiwan JINGYUAN with original packaging)
Source power: 24W, 36W, 72W, 90W, 120W (optional)
Power efficiency: 85%
Power factor: 95%
Electricity level: II
LED quantity: Optional
Wavelength: R(620-630nm), G(520-530nm), B(465-475nm)
Lighting Angle: 15° , 30° , 45° , 60° , 90° , 120° , 60*120° , (optional)
IP: IP65
Control configuration: Internal controlled by SCM, adopting signal wire to realize synchronous control between luminaires; DMX512 control or 485 control, full-automatic and intelligent controlled by PC.
Color range: 16777216(24Bit) additive RGB colors; 16700, 000 RGB complex true colors; Realize synchronization, chase, moving water, gradual change etc.
Working voltage: 36V-48V
Input voltage: AC110-240V (switch power supply)
Luminaire color: Silver grey, transparent and tempering glass
Wire: Four cores wire and two cores wire(Temperature resistant, cold-resistant, aging-resistant and uvioresistant UL-94V0)
Material: Aviation aluminum with good quality, die-casting cover (ABS+EC), plastics ejection and anodization on the surface. Radiator adopts large-tonnage extrusion and digital control processing. Professional pressurize technology, IP65 and durable.
Working temp: -30° C-50° C
LED lifespan: 50000hrs
Operating environment temp: -30-60
Operating environment humidity: 10%-99%RH
|
No. |
Type |
Name |
Dimension |
Voltage |
Power |
Color |
LED |
Power of 1 LED |
|
1 |
MY-XQ220024R-01 |
Wash wall light |
500X100 |
AC: 220V |
24 |
Red |
18 |
1 |
|
2 |
MY-XQ220024G-01 |
Wash wall light |
500X100 |
AC: 220V |
24 |
Green |
18 |
1 |
|
3 |
MY-XQ220024B-01 |
Wash wall light |
500X100 |
AC: 220V |
24 |
Blue |
18 |
1 |
|
4 |
MY-XQ220024Y-01 |
Wash wall light |
500X100 |
AC: 220V |
24 |
Yellow |
18 |
1 |
|
5 |
MY-XQ220024W-01 |
Wash wall light |
500X100 |
AC: 220V |
24 |
White |
18 |
1 |
|
6 |
MY-XQ024024X-01 |
Wash wall light |
500X100 |
AC: 24V |
24 |
DMX512 |
18 |
1 |
|
7 |
MY-XQ220040R-01 |
Wash wall light |
500X100 |
AC: 220V |
40 |
Red |
30 |
1 |
|
8 |
MY-XQ220040G-01 |
Wash wall light |
500X100 |
AC: 220V |
40 |
Green |
30 |
1 |
|
9 |
MY-XQ220040B-01 |
Wash wall light |
500X100 |
AC: 220V |
40 |
Blue |
30 |
1 |
|
10 |
MY-XQ220040Y-01 |
Wash wall light |
500X100 |
AC: 220V |
40 |
Yellow |
30 |
1 |
|
11 |
MY-XQ220040W-01 |
Wash wall light |
500X100 |
AC: 220V |
40 |
White |
30 |
1 |
|
12 |
MY-XQ024040Q-11 |
Wash wall light |
500X100 |
AC: 24V |
40 |
Rainbow colors |
30 |
1 |
|
13 |
MY-XQ220120R-01 |
Wash wall light |
500X100 |
AC: 220V |
120 |
Red |
90 |
1 |
|
14 |
MY-XQ220120G-01 |
Wash wall light |
500X100 |
AC: 220V |
120 |
Green |
90 |
1 |
|
15 |
MY-XQ220120B-01 |
Wash wall light |
500X100 |
AC: 220V |
120 |
Blue |
90 |
1 |
|
16 |
MY-XQ220120Y-01 |
Wash wall light |
500X100 |
AC: 220V |
120 |
Yellow |
90 |
1 |
|
17 |
MY-XQ220120W-01 |
Wash wall light |
500X100 |
AC: 220V |
120 |
White |
90 |
1 |
|
18 |
MY-XQ048120X-01 |
Wash wall light |
500X100 |
DC: 48V |
120 |
DMX512 |
90 |
1 |
