Product parameters table:
Input voltage: AC85-265V
Frequency: 50-60Hz
Power factor(PF): >0.9
Power Consumption: 15W
LED luminous efficiency: ≥ 80LM/W
Color rendering index(CRI): Ra>70
Working temperature: -30º C-50º C
Storage Temperature: -40º C-80º C
Lifespan: >50000Hrs
LED type: --
Net weight: 1400G
Viewing Angle: 30°
Dimension(Unit: Mm): L270*W90*H115
Protection grade (IP): 65
Part No. |
Color |
Q‘ty of LEDs (pcs) |
Color Temp/Wavelength
Typ (kelvin/nm) |
luminous flux
(lm) |
MY-XQ220015W |
Warm White |
15 |
3000K |
1350-1500lm |
|
White |
|
6000K |
1350-1500lm |
|
Red |
|
624nm |
675-825lm |
|
Green |
|
525nm |
750-900lm |
|
Blue |
|
470nm |
225-375lm |
|
Yellow |
|
589nm |
525-675lm |
