Technical Parameters
| Item | Parameter |
| Model | P4 indoor full color LED module |
| Module size | 256mm * 128mm*85mm |
| Pixel pitch | 4mm |
| Pixel density | 62500dots/m² |
| Pixel configuration | 1R1G1B |
| Module resolution | 64dots(W) * 32dots(H) |
| Max power consumption | 18W |
| Module thickness | 13.07mm |
| Module weight | 0.18KG |
| Driving method | Constant current driving |
| Scan method | 1/16 scan |
| Interface way | HUB75-A |
| Brightness | ≥1500cd/m² |
| Cabinet size | 512mm * 512mm |
| Power supply mode | 5V/40A*2pcs |
| Thermal discharge | Fan 2pcs |
| Optimal viewing distance | 4M - 20M |
| Optimal viewing angle | 160º(W) 120º(H) |
| Environment temperature | -20º ~ +50º |
| Relative humidity | 10% - 95% |
| Operating voltage | AC220V ± 10% |
| Average power | 85W/H |
| Max power consumption | ≤160W/m² |
| Current | ≤20MA |
| CPU | WIN98/2000/NT/XP |
| Control mode | Synchronization |
| Driving device | IC constant current driving |
| Refresh rate | ≥400HZ |
| Gray/Color | RGB each 256 grade,can display 16.7M color |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
| Display mode | 800*600/1024*768 |
Product Features
Energy saving design,good cooling system,high-definition,high cost,outstanding reliablity and complete
function by the majority of new and old customers favrite
Ultra-high refresh rate,support the camera recorder,to ensure a clear picture quality
Quick editing of assembly,disassembly system,saving unloading time.
Application.
Widely used in a variety of needs large hall,sports arena,banks,telecommunications,government agencies,
terminal,the stock market and other trading market,advertising,etc..
