Features:
1. Green Initiative, no harmful substance like lead, mercury, comform to RoHS standard.
2. Wide voltage design, can be used directly when the input is 85 to 265VAC range, reduced the load of power system with higher power.
3. No stroboscopic, LED use constant current drive, guarantee the reliability, quick start.
4. PAR30 and PAR38 use aluminum alloy as heat-radiating structure guarantee excellent performance of radiator, lamp holder use E7
5. Unique optical design, lighting Angle optional, strong light directivity, achieves the best illume effect.
6. Have more than 5 years lifespan.
Application: Suitable for stage, boutiques, boutique, market and household decorative lighting etc.
|
Type |
MY-PAWRV008C-01 |
|
Input Voltage |
85— 265VAC |
|
Frequency Range |
50— 60Hz |
|
Power Factor(PF) |
0.7 |
|
Power Efficiency |
85% |
|
Working Voltage |
DC23V |
|
LED Consumption |
7w |
|
System Consumption |
8W |
|
LED Chip Manufacturer |
EPISTAR |
|
LED Luminous Efficiency |
> 90Lm/W |
|
LED Initial Flux |
> 630Lm |
|
Lamp' s Efficiency(%) |
> 75% |
|
Beam Angle |
30° |
|
Average Illumination 0.5m |
1320 |
|
1m |
385 |
|
1.5m |
145 |
|
2m |
90 |
|
Color Temperature |
5000K-6000K |
|
Color Rendering Index(CRI) |
> 75 |
|
Junction Temperature |
< 65º C |
|
IP Rating |
IP65 |
|
Working Life |
> 30000hrs |
|
Light Body& Lampshade Material |
Aluminium Alloy+PC/PMMA |
|
Net Weight/Gross Weight |
0.24kgs/0.28kgs |
|
Packaging Size(L)*(W)*(H) |
100mmX100mmX100mm |
