Applications
Can be used in the office, schools, hospitals, hotels, conference room lighting and other places
Features
Energy saved up to 50%. High brightness even lighting output.
Imported high brightness 3014 LED light bead, high CRI, low light decay.
Special circuit design, each group of LEDs work separately, avoiding any problem of lighting output caused or influenced by single faulty LED New high efficiency constant current driver. Wide range of input voltage: AC100-240V.
No delay start. No waiting. It can reach its normal light as soon as it is turned on. No noise.
No electrical wave, conforming to CE.
Environment friendly and no air pollution. We exert the design of using cold light source. It's no heat radiation. There is no ill to our eyes and skin. The floodlights do not have lead, hydrargyrum and any other contamination. It is really environment friendly with RoHS certificate
|
MAIN SPECIFICATIONS (T=25 ) |
|
NUMBER |
ITEM |
DESCRIPTION |
|
01 |
Input Voltage |
AC100-240V 50-60Hz |
|
02 |
LED |
180pcs |
|
03 |
Power |
18W |
|
04 |
LED Efficiency |
70-80Lm/W |
|
05 |
Initial Flux |
>1450Lm (Cool White)
>1400Lm (Natural White)
>1300Lm (warm white) |
|
06 |
Power factor |
>0.95 |
|
07 |
Color |
Warm White/Natural White/Cool
White/Red/Green/Blue/Yellow |
|
08 |
Color Temperature |
2700-3300K (Warm White)
4000-5000K (Natural White)
5300-7000K (Cool White) |
|
09 |
Center Illuminance |
1M:560 Lux
2M:163 Lux
3M:78 Lux |
|
10 |
Beam Angle |
120° |
|
11 |
Life Time |
>50,000 Hour |
|
12 |
Operating Temperature |
-25 to +55 |
|
13 |
Storage Temperature |
-40 to +65 |
|
14 |
Connect Wire |
Brown L
Blue N
Yellow/Green G |
|
15 |
Certifications |
CE, RoHS |
|
16 |
Weight |
1.23Kg |
|
17 |
Size |
295×295×11.5mm |
|
18 |
IP Code |
IP20 |
Shenzhen Guoren Photoelectric Co., Ltd. is a professional lighting electric product manufacturer. we won the wide recognition and praises of our customers by virtue of high quality. and excellent spirit.
We are specialized in manufacture, research and development, and wholesale of middle and high-grade LED products. Our company has a professional engineering service team, a lean marketing team, a regional highly skilled after-sales service team and a good faith logistics support team, and is equipped with high skills and good after-sales service.
Our products include LED light bead, light source, LED tube light, LED panel light, LED high bay light, LED flood light, and all other indoor and outdoor lighting.
As a lead enterprise, be professional in the R& D, manufacturing and lighting control solution for LED lighting products, GR does its best to serve the advanced-tech and excellent quality LED lighting products to its valued clients all round the world. our factory is located in shenzhen, and have two offices in shenzhen and one office in HK.
Our company has been adhering to the operation philosophy of "Detail makes perfect; Everything is possible", and the work style of "good faith, practical, efficient, rigorous". We have won the general customers' recognition and full cooperation. With advantages of high-quality products, circumspect services, complete storage, timely delivery, etc., our company won the unanimous favorable comment from a huge group of customers. We believe that our younger team which is full of vigor and vitality will gather together to strive for the new chapter of success.
Engineered
Backed with our own expertise of mechanical, electronic, optical and thermal engineering, GR also leverages expertise from our strategic partners and associatedcompanies through comprehensive collaborations. Our strong R&D background enables us to offer turn-key LED solutions for the architectural lighting, retail and display lighting industry. High technical reliability of GR LED products will help maximize your energy savings while minimize your TCO (total cost of ownership).
Customized
Can not find what you exactly need in the market? Turn to GR to design and manufacture your LED solutions. We'll leverage from one or more of our standard products to bring your LED products to market quickly with minimized cost and maximized values.
Certified
All GR LED products are certified by independent parties which are authorized by re-known labs or organizations. This ensures our customers can have all required certificates for their target markets. Partnership with the world's best LED solutions providers makes sure that our customers have the accessibility to the latest LED technology.
