CreateLED's conventional screens are managed by advanced and professional for video screen drive and control systems. They are capable of visualizing more than 281 trillions of colors with a resolution of 16 bit continuously per color. With pixel-sharing technology. CreateLED displays always deliver to all of our customers with excitement!
The basic protection of video screen guarantees a better and longer lifetime. CreateLED has focused on developing this feature and can manufacture all the screens to a protection level of IP65 on the front side, and IP54 on the rear side with iron with cotton filter, which completely isolates the screens from rain and dust. Besides all cabinets with 1000mmx100Omm, which are enable to fit customers ideal screen size.
1. Perfect height: The perimeter LED display and sport advertising board are available in several heights. The safe height could reach 960mm
2. High resolution: CreateLED perimeter LED display could provide pixel resolution of pH-10(10, 000pixels/m2), pH-12(27, 776 pixels/m2, virtual pixel solution), pH-16(15, 624 pixels/m2, virtual pixel solution), pH-20(10, 000 pixels/m2).
3. Impact resistant: CreateLED perimeter LED display's protection flex surface mask are made of half-carbon fiber flex mask, it's more light weight but more stronger than common flex surface mask.
4. Waterproof cabinet: CreateLED perimeter LED display has pass waterproof test, it could be protected against from any stadium environment, such like water, rain, dust and grass clippings, the protection level could reach IP65 for front side and IP54 for rear side.
5. Adjustable Viewing Angle: The brackets are adjustable on angle, gradient of the perimeter display can be changed easily according the viewers viewing angle.
6. Special design: According to fellow the customer's habit, the rear door of the cabinet has corn-cut design, so that the rear door could be opened when the cabinet angle was adjusted down.
7. Easy to assemble and transportation: Because the perimeter LED displays have integrated pull down rear back support brackets it enables easy transportation in flight cases and easy installation. You only need to pull down the brackets on the floor and then the perimeter LED display can be supported on the ground.
|
PH-12 |
Pixel Pitch |
12mm |
Unit Size |
960mmx768mm |
LED Type |
2R1G1B |
Pixel / Unit |
80x64 |
Unit Weight |
48kg |
Viewing Angle |
H160° V70° |
Application |
Storage-40~60° C, Working-20~50° C |
Protection Level |
IP65/IP54 |
Power Consumption |
420W/panel Max |
|
168W/Panel Ave. |
Driving |
1/4 Scan |
Frame Refresh |
≥ 60Hz |
Data Refresh Rate |
600~2, 000Hz |
Processing |
16bit |
Max Output Brightness |
5, 500-6, 500nits |
Power Supply |
AC90-240V, 50~60Hz |
MTBF |
≥ 1, 000 Hours |
Life Span |
≥ 50, 000 Hours |
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
