P4 mm competitive price slim led module
1. Our Service
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM, any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area, ideas of design and all your private information
5)Top Quality+Reasonable Price+Responsible After Service=Successful & Win
2. Trade Terms
1. Payment: T/T, 30% deposits before production, 70% balance to be paid before dleiverying
2. Shipping freight are quoted under your requests
3. Shipping port: ShenZhen, Mainland China
Product Description
Products Description:
P4 Full Color LED modules for indoor LED Screen
Module Size: 256*128mm
Density/sq.m: 62500dots
Module Resolution: 64*32
Specification: | P4 LED Panel Specification |
|
| NO: | Product Name | Specification |
| 1 | Pixel Pitch | 4mm |
| 2 | Pixel Configuration | 1R1G1B/SMD2121 Black lamp |
| 3 | Density | 62500 pixel/m2 |
| 4 | Moduel Size(L×W)mm | 256mm×128mm |
| 5 | Cabinet Size(L×W×H)mm | 512mm×512mm×130mm |
| 6 | Module Resolution | 64×32 |
| 7 | Cabinet Resolution | 128*128 |
| 8 | Driving Method | 1/16Scan |
| 9 | Driving IC | MBI5024 |
| 10 | Brightness | 2300cd/m2 |
| 11 | Contrast | 1000:1 |
| 12 | Brightness Adjustment | Auto and Manual |
| 13 | Power Consumption | Max Power:<1300W |
| 14 | Average power: <735W |
| 15 | Module Weight | 0.2kg |
| 16 | Color Temperature | 3200K-9300K |
| 17 | Horizontal Viewing Angle | 120º |
| 18 | Vertical Viewing Angle | 120º |
| 19 | Signal Processing | 10 or 14bit |
| 20 | Grey Processing | 1024×1024×1024
16834×16834×16834 |
| 21 | Control Distance | cable100m,Multimode500m,Single mode 2km |
| 22 | Frame Frequency | 65 Hz |
| 23 | Refresh Rate | >3500Hz |
| 24 | Control Mode | Synchronous/Asynchronous |
| 25 | The Opposite Calibration Curve | With Eight Optional Gamma Calibration Curve |
| 26 | Users can choose the recommended curve or adjust it based on actual situation |
| 27 | MTBF | >50000 hours |
| 28 | Life Span | 100,000 Hours |
| 29 | Operating Temperature | Working : -20 - 65 ºC |
| 30 | Storage : -40 - 85 ºC |
| 31 | Environment Temperature | -30ºC to 60ºC; humidity Rh10% to 95% |
| 32 | Remote Control | Can realize remote control and send alarm signal to operators in case of logging failure (Be customized) |
| 33 | Self-checking Technique | Self-inspection, communication test, power test, temperature monitoring (Be customized) |
| 34 | Operating System Platform | WindowsNT,Windows2000,WindowsXP,Windows7 |
| 35 | Power Supply | AC 85-264V |
| 36 | Protection | waterproof, dustproof, high temperature pervention, anticorrosion, smoulderproof, anti-static, shockproof, lightningproof, smoke alarm and temperature alarm. (Be customized) |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
