1. Use integrated powerful LED as the light source, with our own intellectual property rights for LED encapsulation.
2. Use the high pure imported aluminum from Germany as the reflector. This kind of reflector has high reflecting efficiency, and it can make sure the luminous flux.
3. Good heat dissipation design, fin-shaped radiator, large radiating area to reduce the temperature, and increased the lamp life.
4. Environment friendly and no air pollution. We exert the design of using cold light source. It is no heat radiation. There is no ill to our eyes and skin. It is a real environment friendly and saving power product.
5. Integrative design for heat sink and housing. The LED is closely connected to the surface. The heat from the LED is removed through the heat dissipation wing and also by air ventilation. This ensures 50, 000 hours life-span for the LED. If it works 11-12 hours per day, it can work over 10 years.
6. The high bay light is controlled by constant current and constant voltage. Its working voltage (AC 85-265/90-305V) can overcome the electrical grid, noise pollution and unstable light caused by ballast.
7. No delay start. It can reach its normal light as soon as turn on. The switch can be used for hundreds of thousand times.
8. Obvious power-saving efficiency. Use powerful LED light source and high efficiency imported LED driver. Compare with ESL/CFL, it can save electricity around 60%.
1) LED Power Consumption: 1*30W/1*50W/1*80W/1*100W
2) Lumen Output: ≥ 2940LM/4900LM/7840LM/9800LM&CCT-6000K
3) Power Supply Consumption: 33.4W/55.6W/88.9W/111.2W
4) Input Voltage: AC 85-265/90-305V
5) Power Factor: 0.98± 5%
6) Power Efficiency: ≥ 90%
7) Base: 3 PIN Wires
8) CCT: 2700-7000K
9) CRI: WW≥ 80, CW≥ 75
10) Beam Angle: 120
11) Working Temperture: -40-50 degrees
12) Body Temperature: <55 degree (Ambient Temperature 25 degrees)
13) Working Humidity: 10%~90%
14) Life Time: >50, 000hours
15) IP Rating: IP54
16) Size: 413(D)*270(H) mm 30W 413(D)*290(H) mm 50W
413(D)*351(H) mm 80W 413(D)*383(H) mm 100W
17) Net Weight: 1.8Kg 30W, 2.2Kg 50W, 3.0Kg 80W, 3.5Kg 100W
18) CE, FCC, SAA, PSE, RoHS approved
19) Warranty: 3/5 years.
We (CMC Shanghai PUDONG CORP. ) develop, manufacture, and sell semiconductor lighting systems particularly high-power LED based products. Through self-funded research and development and proprietary technologies and products, our primary goal is to deliver green lighting systems to our customers. Our proprietary high-power LED product was appraised as "industry-leading" technology by government agents in China. As a pioneer in semiconductor lighting industry, our company is highly regarded by customs around the world.
Our proprietary high-power LED lighting technologies are bringing truly green lighting products to our society. More importantly, our products will fully take advantages of the unique properties of semiconductor lighting, including extremely high energy-efficiency, long lifetime, rich and saturated color, environment-benign, etc.
Our present product portfolios include outdoor and commercial lights. These products are designed based on several industry-leading technologies. These technologies include, but are not limited, advanced switch power supply, comprehensive thermal management technology, and state-of-the-art design. The new features of our lighting systems include, but are not limited to, energy-efficient, environmentally-benign, new functionalities. In particular, we are exploiting and extending the new concept of lighting, which is a natural combination of light and life. To achieve these goals, we have companies and branches located both in China and USA.
