AirLED-6 Black Face Features
Black face 6.25mm pitch SMD LEDsBlack face SMD technology with high contrast, plus the new design advanced light trap louver, offering outstanding image quality.
Seamless and LightweightStructure made of precision extruded aluminum, completely seamless due to a complete revamp of our cabinet frame using an intelligent interlocking system, snap locking mechanisms makes the rapid set up and teardown in a few seconds.
Weight including structure and cables is only 7kg/panel, 28kg/sqm, which is ideal for setup and teardown as well as economical crating and transport.
Extra wide viewing angleUltra wide viewing angle, clear visible image from nearly all angles.
Advanced video processing, breathtaking grayscaleProvides 16 bit image processing for 281 trillion colors resulting in a crystal-clear picture with true-to-life color reproduction. Vibrant images with deep, with a tight selection of LEDs to get uniform colors across the entire display surface, detailed image with smooth motion reproduction, the color triangle of AirLED-6 is actually much wider than normal.
Consistent uniformityHighly efficient black body LEDs, double size chip, lower LED temperatures.
Standard design & Standard componentsAll AirLED series design with the standard size of 500mmx500mmx65mm panels and standard size of 250mmx250mm modules, uses industry-standard power and signal interconnects to reduce display downtime and replacement costs.
Product Description
Indoor LED Video Display Screen:
1. Ultra-light weight and slim design
2. Fanless design and front maintenance
3. Quick lock system allowing handling fast
4. Standard panel size 500mmx500mm making flexible assembling and dismantling
5. High refresh rate available for capture for DV&VCR
|
|
AirLED-6 |
|
Pixel Pitch |
6.25mm |
|
Unit Size |
500mmx500mmx73mm |
|
LED Type |
SMD 3-IN-1 |
|
Pixel / Unit |
80x80 |
|
Unit Weight |
7kg |
|
Viewing Angle |
H160 degree V100 degree |
|
Contrast Ratio |
2000: 1 |
|
Application |
Storage-40~60 ° C, Working-20~50 ° C |
|
Protection Level |
For indoor use only |
|
Power Consumption |
150W/panel Max |
|
80W/Panel Ave. |
|
Driving |
1/8 Scan |
|
Frame Refresh |
≥ 60Hz |
|
Data Refresh Rate |
1, 200~4, 000Hz |
|
Processing |
16bit |
|
Max Brightness |
2, 000nits |
|
Power Supply |
AC90-240V, 50~60Hz |
|
MTBF |
≥ 1, 000 Hours |
|
Life Span |
≥ 50, 000 Hours |
|
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
