Full color die casting indoor SMD LED display screen AiRLED-3:
CreateLED AirLED Die-Casting series is a revolutionary design for both rental and permanent installations. Fan-less design resulting in noiseless suitable to be installed in the high-end performance like Car Show, TV station, Retails.
Die-Casting design technology allows it ultra-thin, lightweight enclosure requiring no tools for deployment and servicing.
Deepest Black level design-Totally black body and revolutionary black body LEDs makes the display delivers the deepest black level in the market, and the highest attractive contrast ratio of over 4000: 1.
1. Standard dimension 500mmx500mm-reduced delivery time and easier inventory management by our client.
2. Die-casting by laser cutting with sleek design, 8KG/cabinet
3. Unique design- Tai chi rear cover design with two color option;
4. Convenient and Fast installation-one person can install at least 60 cabinets per hour.
5. High Precision_processed by high precision CNC machine, the size is accurate to 0.1 mm.
6. Saving energy_ only 150W max power consumption/ 60W average power consumption for each panel.
|
|
AirLED-3 |
|
Pixel Pitch |
3.9mm |
|
Unit Size |
500mmx500mmx65mm |
|
LED Type |
SMD 3-IN-1(black body) |
|
Pixel / Unit |
128x128 |
|
Unit Weight |
7kg |
|
Viewing Angle |
H160 degree V100 degree |
|
Contrast Ratio |
4000: 1 |
|
Application |
Storage-40~60° C, Working-20~50° C |
|
Protection Level |
For indoor use only |
|
Power Consumption |
200W/panel Max |
|
80W/Panel Ave. |
|
Driving |
1/16 Scan |
|
Frame Refresh |
≥ 60Hz |
|
Data Refresh Rate |
600~2, 000Hz |
|
Processing |
16bit |
|
Max Brightness |
1, 200nits |
|
Power Supply |
AC90-240V, 50~60Hz |
|
MTBF |
≥ 1, 000 Hours |
|
Life Span |
≥ 50, 000 Hours |
|
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
