CreateLED AirLED-6, combining ultra-lightweight design with remarkable high-performance with cost-efficient, this LED display is the classical, enduring product, the smart choice for events or indoor installation applications product. With output of 1, 500 Nits and 16 bit color processing, this LED video display is sure to deliver the super amazing image quality in any indoor setting.
Each AirLED-6 panel measures an standard of 500mm x 500mm in size with a thickness of just 65mm including the intelligent louver, giving an ultra light weight display of only 7kg per panel (28kg per square meter only). It's an ideal solution for applications which the weight loading limited, and the maximum creative freedom is needed.
Key Benefits
1. Budget friendly product, ideal for basic rental and fixed installations.
2. Extremely close view distances and wide view angles.
3. Silent operation, little heat generated (no fans).
4. Standard panel design makes stocking, transportation, construction, spare parts and maintenance easy and simple.
5. Lightweight and seamless, precision extruded aluminum section structure.
6. Environmentally friendly.
7. Low power consumption.
|
AirLED-6 |
|
|
Pixel Pitch |
6.25mm |
|
LED Type |
3-in-1 SMD |
|
Brightness |
1, 500nits-1, 800nits |
|
Viewing Angle |
H: 160 degree |
|
V: 100 degree |
|
Contrast Ratio |
2000: 1 |
|
Pixel Density |
25, 600/sqm |
|
2, 381/sqf |
|
6, 400/panel |
|
Module Size |
250mm x 250mm |
|
Module Resolution |
40 x 40 |
|
Panel Size(WxHxD) |
500mmx500mmx65mm |
|
Panel Resolution |
80 x 80 |
|
Weight |
7kg/panel |
|
Power Consumption |
200W/Panel Max |
|
80W/Panel Ave |
|
Processing |
16 bit/color |
|
Refresh Rate |
600-2, 000Hz |
|
Drive Method |
1/8 Scan Method |
|
Environment |
Indoor use only |
|
Max Stacking |
20 panels |
|
Max Hanging |
20 panels |
|
Servicing |
Front & Back |
|
Panel Material |
Precision Extruded Aluminum Section |
|
Source Compatibility(with Processor) |
VGA(RGBHV), DVI, HDMI, SDI(HDSDI) |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
