| Price: | US $ 1500/Square Meter |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 1/Square Meter |
| Pay Type: | L/C,T/T,Western Union |
Pixel configuration | SMD2020 1R1G1B 3 in 1 | |
| LEDs configuration | Red:wave length: 625~630nm;300-400mcd Green:wave length: 525~530nm;600-800mcd Blue:wave length: 470~475nm;100-150mcd | |
| Pixel pitch(mm) | 4 | |
| Pixel density(dots/sqm) | 62500 | |
| Calibrated brightness(cd/sqm,nit) | 1800 nits(adjustable) | |
| Calibrated brightness proportion ratio | R:G:B = 3:6:1 | |
| Contrast ratio | 4,500:1 | |
| Brightness adjustment(dimming) | 100 grade auto/manual-adjustment | |
| View angle(degree)(50% brightness) | V140/H140 | |
| Color capability | 4.4 trillion | |
| Refresh rate(Hz) | >800 Hz | |
| Frame frequency(Hz) | >60 Hz | |
| Interface port | DVI interface(DVI connector) | |
| Input signal | VGA, Video, AVI, MOV, MPG, DAT, VOB etc. | |
| LED Drive | Constant-current drive | |
| Lifetime(hours)(50% brightness) | 100,000 hours | |
| Signal transmission direction | Horizontal | |
| Operating temperature(Celsius degree) | -30 ~ 65 | |
| Storage temperature(Celsius degree) | -35 ~ 70 | |
| Operation humidity(RH) | 0-95% | |
| Operation humidity(RH) | 0-99% | |
| Service | Front and back service optional | |
| Control mode | Synchronous & asynchronous available | |
| Communication options | Wire Ethernet, Fiber Ethernet,RF wireless,GPRS | |
| Power | 120/240 VAC single phase(50-60Hz) | |
| Maximum power consumption(W/sqm) | 900 | |
| Average power consumption(W/sqm) | 360 | |
| Screen operation mode(scan/static) | 1/16 | |
| Module configuration(Pixels quantities of the module) | Length | 72 |
| Height | 72 | |
| Module dimensions(mm) | Length | 288 |
| Height | 288 | |
| Cabinet configuration | Length | 144 |
| Height | 144 | |
| Cabinet dimensions(mm) | Length | 576 |
| Height | 576 | |
| Width | 90(+module thickness) | |
| Recommend Optimal Viewing Distance: Minimum & Maximum | Min | 2 |
| Max | 54 | |
| Aspect Ratio(L:H) | 4:3 or 16:9 | |
| Packaging configuration | 1~6 standard cabinets in a packing case | |
| Packing material | Wooden case/carton/flight case(optional) | |
| Packing weight(KG) | net | 35KG/m2 Aluminum |
| gross | 40KG/m2 | |
| Prod Model: | P4 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Delivery Time: | Within 7 Days |
| Display Type: | LED Video Display |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Scanning Mode: | 1/8 Scan |
| Certification: | ETL |
| Pixel Configuration: | 1R,1G,1B |
| Pixel Pitch: | 4mm |
| Application: | Shopping Guide |
| IP Rating: | IP43 |
| Pixel Density: | 62500 |
| System Operating Platform: | W XP/ W7 /W8, |
