Indoor 54PCS*3W Edison LED PAR
Voltage: AC90V-250V (50/60Hz);
Rated Power: 170W;
LED lamp: Edison 3W high power LED with long life 50000-100000 hours, high luminous efficiency, no radiation and low power consumption etc;
LED Qty: 54LEDs (12red +14green +14 blue +14 white);
LED Lamp powr supply: Adopt power factor correction PFC switching power supply, PF> 0.99, the efficiency of up to 90%, it's real green and environmental protection;
LED drive mode: Adopt static constant current drive mode with high precision and non-flicker (400Hz);
Projection distance: 20M
Waterproof grade: IP20
Control Mode: DMX512 signal 3-pins connection control / master-salve control / sound control with self-programming mode, self-running mode, extral control mode;
Channel: 4CH, 8CH two channel modes;
Color: RGBW color mixing system with color rainbow and can show multi-colors by
Adjusting white LED; And HSL color mixing adjustment which is the most favorite color mixing way for lighting technician;
Len: High optical transmission acrylic lens;
Emitting angle: Standard 15 ° , and 8 ° , 25 ° , 30 ° , 45 ° , 60 ° Is optional;
Dimmer: 0~100% linear dimmer;
Strobe: Multi-function electronic strobe effects from 1 to 25 times per second or randow strobe;
Material: Aluminum alloy plus plastic;
Maximum working terperature: 45° C
Maximum surface temperature: 60 ° C
Application: Lighting for TV studio, theater, opera house, auditorium, stage, T-stage, concerts, and vocal concert,
DJ effect, disco effect, club effect, party effect etc;
Dimensions: 290*235*235 (mm)
Package size: 300*330*350 (mm)
Gross weight: 7.5kg
|
Channel |
function |
|
Ch 1 |
Lamp on |
|
Ch 2 |
RED |
|
Ch 3 |
GREEN |
|
Ch 4 |
BLUE |
|
Ch 5 |
White |
|
Ch 6 |
Strobe effect |
|
Ch 7 |
Speed |
|
Ch 8 |
Soft light function |
