High Refresh Rate P7.62 smd3528 indoor led display
FEATURES
Long lifetime: Adopting high quality LED lamps as core material and patent PCB design for the screen, it essentially ensures long lifetime fo the product.
Wide view angle: Highly wavelength consistency of LED lamp and 120°horizontal and vertical view angles guarantee viewers can see the playing miages from any direction in front.
Stable performanve: we make a spceial treatment of anti-electromagnetic wave and adopt distribution scan and modular design for the screen and it works more reliable and stables.
Exquisite images: Nonlinearity correction technology makes the images exquisite clear, video images vivid and fidelity.
Excellent flatness: percision design of module frame parts controls the deviation of beighbouring modules within 0.1mm and it has an excellent flatness without mosaic..
High contrast:consistend deep black patent masks and black face lamps make the contrast higher and the color fresher.
Live broadcast: It can support DVI,HDMI, 3G/HD/SC with SDI high definition display mode, suit for TV programes VCDprogrames, DVDprogrames and live broadcasting indoor .
Easy installation: Modular design makes the installation and maintance easier.
Good material:Adopting same levels of imported LED chips from taiwan, USA or Japan, high quality driving IC, low nosie power supply, which can guarantee the screen works mooth in the environment of -20 degree to 40degree.
Multiple formarts: Customers can choose any one of display formats for the screen, it can supports TXT, graphoc, picture animation and video programe.
Lacquer coating: Lacquer coasting can protect the PCB and relevant components from erosion of environment, it has the good resistance performance of low and high temperature, and excellent features of insulation, moisture proof, anti-creeping ,dustprrof,anti-corrosin.
High shockproof performance: The cabinets must be tested for shockprrof performance before shipment to avoid poor contact because of loose of screws and disconnection of cables after ling line -haul.
PH7.62 |
Pixel pitch | 7.62mm | LED encapsulation | SMD3528 |
Module resolution | 32×16 dots | View angle | 140°/140° |
Module size | 244×122 mm | Working environment temp | Temp: -20 °C to +60 °C Humidity: 35%~85% |
Pixel density | 17,222 dots/m² | Working voltage | 110 V±15% or 230 V±15% |
Pixel configuration | 1R1G1B | Driving method | 1/8 scan, constant current |
Optimun Viewing distance | >6 m | Gray level | RGB/8192/14bit |
Max power consumption | 800 W/m² | Display function | Graphics,Animation, and video |
Brightness | >1500 CD/m² | Refresh rates | > 800Hz |
Life span | >100,000 hours | Blind spot rate | < 0.00001 |
Shenzhen Huaxia L&C Display Technology Co., Ltd(CLC display company), a LED display company located in Baoan district, Shenzhen. Based on our 3 factories(total 15200 square meters), we designs and develops visualization solutions for a variety of products selected from professional markets: Advertisement, Media, Sports, Entertainment, digital cinema, CCTV security, simulation & virtual reality. In these markets, Huaxia offers user-friendly imaging products that optimize productivity and business efficiency.
Integrating visualization technology requires specialist know-how and expertise and that's exactly what we can offer you - before, during and after the sale. We offers a complete range of high-impact video display systems, image processing and content management technology for permanent installations, rental and staging markets. Based on our staff with a couples of experience, We provide the right visualization technology to match your needs.
As a OEM/ODM factory, we are supplying both LED display and LED module to the overseas and domestic buyers. We supports our customers to finish more than 1, 500 events every year, which are from more than 60 countries and regions.
Main product list:
Indoor display, outdoor display, outdoor/indoor display mesh
Pixel pitch:
From P1.5, P1.875, P3.0, ...P31.25
Application locations:
Outdoor, Indoor and semi-outdoor
Application markets:
Advertisement, Media, Sports, Entertainment, Digital cinema, CCTV security, Simulation & virtual reality
