1. High brightness and adjustable according to the application environment;
2. Save 30% power consumption compared with common products;
3. Having good lightening accordance and no mosaic;
4. Using virtual pixels, better viewing effect for both text & graphic and video;
5. Having larger viewing angle: Horizontal angle 160 degree/elevation angle 70 degree. Getting vivid effect within any position of the viewing range;
6. Any LED in died pixel can be respectively repaired, which reduce the cost of the display maintenance.
CreateLED's Advertising Billboard Full Color Video Display Board LED Display (pH-10) are managed by advanced and professional for video screen drive and control systems. They are capable of visualizing more than 281 trillions of colors with a resolution of 16 bit continuously per color. With pixel-sharing technology. CreateLED displays always deliver to all of our customers with excitement!
The basic protection of video screen guarantees a better and longer lifetime. CreateLED has focused on developing this feature and can manufacture all the screens to a protection level of IP65 on both front side and back side with iron with cotton filter, which completely isolates the screens from rain and dust.
Full Color Display, Full Color LED Display, Full Color LED Display Screen, Outdoor Full Color Display, Full Color LED Display Board, Full Color Video LED Display, Advertising Billboard Screen, Outdoor LED Display are available.
|
Model |
PH-10 |
|
Pixel Pitch |
10mm |
|
Unit Size |
800mmx800mm |
|
LED Type |
1R1G1B (vertical arrangement) |
|
Pixel / Unit |
80x80 |
|
Unit Weight |
40kg |
|
Viewing Angle |
H160° V70° |
|
Application |
Storage-40~60° C, Working-20~50° C |
|
Protection Level |
IP65 |
|
Power Consumption |
325W/panel Max |
|
130W/Panel Ave. |
|
Driving |
1/4 Scan |
|
Frame Refresh |
≥ 60Hz |
|
Data Refresh Rate |
600~2, 000Hz |
|
Processing |
16bit |
|
Max Brightness |
5, 500-6, 500nits |
|
Power Supply |
AC90-240V, 50~60Hz |
|
MTBF |
≥ 1, 000 Hours |
|
Life Span |
≥ 50, 000 Hours |
|
Pixel Failure |
< 0.0003 |
Shenzhen CreateLED Electronics Co, . Ltd. Is one of the most professional LED Screen manufacturer to provide full solutions for fixed billboard market and rental market.
Especially since year of 2010 we explored and issued the innovative newly AirLED series for rental customers, standard solution for different applications, standard solution for ourselves mass production.
About outdoor fixed installation billboard, we are promoting the full viewing angle, complete water proof and lower power drive method outdoor cabinets, which is leading the trend of this billboard market.
Welcome to our Showroom and My Products for more detailed offer info.
