Cn 10/12 are rental LED curtain displays, with lightweight, super-thin, and transparent features, suiting for large LED stage background use with quick set-up and take-down. It realizes precise connection, 100 % tool-free structure and high durability. Unit size 500 X 1000 mm; Weight 8 kg; Thickest part with back box only 60 mm and high transparency 45%. Upgraded Cn ensures more safe operation, stable performance and easier front and back maintenance. So, Cn is perfectly suitable for TV Station, TV studio, concert, and various rental stage background, especially in large size application for professional AV rental companies, etc.
Main Advantages:
1. Lightweight, convenient shipping and transportation, suiting for touring and permanent shows;
2. Precise connection, single-person set-up and take-down, no tools needed;
3. Convenient maintenance from front and back side, single panel replacement;
4. Can be curved as +/-10° , arc-shaped available;
5. Hight transparency, go through air, light, smoke without barriers;
6. Indoor and outdoor capable; Indoor with brightness 900-1500 nit, IP 43; Outdoor with brightness 5000 nit, IP 65.
|
Item Name |
Cn10 |
Cn10A |
Cn12 |
Cn12A |
|
Pixel Pitch |
10.4166mm |
10.4166mm |
12.5mm |
12.5mm |
|
LED Type |
SMD3528 |
SMD3535 |
SMD3528 |
SMD3535 |
|
Pixel Matrix |
96x48dot |
96x48dot |
80x40dot |
80x40dot |
|
Pixel Density |
9216dots/ m2 |
9216dots/ m2 |
6400dots/ m2 |
6400dots/ m2 |
|
Brightness |
900-1500 Nit |
4500 Nit |
900 -1500 Nit |
4500 Nit |
|
Best Viewing Distance |
≥10m |
≥10m |
≥12m |
≥12m |
|
Weight |
8kg |
10kg |
7.5 kg |
9.5 kg |
|
Max. Power Consumption |
200W/panel |
300W/ panel |
150W/ panel |
300W/ panel |
|
Ave. Power Consumption |
80W/ panel |
100W/ panel |
60W/ panel |
100W/ panel |
|
Protection Level |
IP43 |
IP65 |
IP43 |
IP65 |
|
Application |
INDOOR |
OUTDOOR |
INDOOR |
OUTDOOR |
|
Unit Size |
500x1000x60mm |
|
Pixel Configuration |
RGB 3in1 |
|
Viewing angle |
140°/140° |
|
Gray Scale |
≥14bit |
|
Refresh Rate |
≥1920Hz |
|
Power Input |
AC220V 50/60HZ |
|
Working Environment |
Temperature -10~+50degree,Humidity 10~90% RH |
|
Tenure Life |
50,000hours |
|
Certificate |
CE |
SHENZHEN VTEAM Co., Ltd. is a professional ODM LED Screen manufacturer in Shenzhen, China, specialized in creative indoor and outdoor LED screen with experienced R&D team who has been working in LED display field for more than 8 years.
VTEAM screen is popular with the features of light weight, ultra-thin cabinet, transparent structures and widely-used in the application of TV Station, studios, auto shows, music concerts, clubs, discos, building facade, outdoor decorative lighting projects, exhibitions, celebrations etc.
As one of leaders of LED Screen suppliers in China, All products carry CE RoHS certification, with perfect designed products, customized solution, superior product and service guarantee, VTEAM has been highly praised by domestic and overseas customers, we have been shipping qualified products and services to more than 100 countries and regions all over the world, such as in the USA, Russia, Germany, Sweden, France, Netherland, Spain, Canada, Brazil, Mexico etc. The most notable of those successful projects is that we have done the creative "Giant Football" for the opening&closing ceremony of 2014 Brazil FIFA WORLD CUP!
VTEAM Mission: To create value and profit for customers!
VTEAM Vision: Being creative concept pioneer!
