Features of the Products:
IP64 rated, waterproof, dustproof, insect proof.
Samsung 5630SMD, internal driver, aluminum driver box for heat dissipation.
80% more energy saving compared with conventional lights
Special surface design for heat dissipation
Certificate: UL CUL TUV SAA RoHS
Beam Angle: 360 degree
Applications:
Warehouse, indoor lighting, street landscape.
Conference / Meeting rooms/ Commercial Complexes
Residential / Institution Buildings/ Schools, Colleges / Universities
Places where need energy saving and high color rendering index lighting
Note: X: W mean Natural White(CW) CCT: 5600-7000K (2 grade: 5600-6300k, 6300-7000k)
T mean Daylight (PW) CCT: 3800-4500K (2 grade: 3800-4000k, 4000-4500k)
L mean Warm White(WW) CCT: 2700-3500K (2 grade: 2700-3000k, 3000-3500k)
Notes: Tolerance of measurement of luminous intensity± 15%
Note:
The warehouse must work under the right voltage according to the specification.
Cut off the current before installation, and make sure the voltage is in right range,
Recommend indoor use
| Part Number | Description |
| PT-CE39-X60A-A00I | ¢*L=105*320mm,198PCS SMD 5630 LEDs, AC100~300V, 50/60Hz, 360 degree, Aluminum +PC |
Technical Specifications:
| Item | Specifications | Parameter |
| Electrical | Input Voltage | AC100-300V |
| Power Consumption | 60±5%W |
| Power Factor | >0.97/110V ,
>0.94/220V ,
>0.9/277V, |
| Frequency Scope | 50/60Hz |
| Operating Temperature | -20~50ºC |
| Photometric | Socket
type | E40,E39 |
| Work Environment | IP64 use |
| Lighting Source | SAMSUNG 5630SMD LED |
| Beam Angle | 360° |
| Life span | >35000h |
| Led qty | 198pcs |
| Dimension | Dimension | ¢*L =105*320mm |
| Net Weight (1pcs) | 1340g±10% |
| Small Box | 145*150*365mm |
| Part Number | Lumens
(LM) | Illuminance(lux) | CRI | CCT |
| 1m | 2m | 3m | 4m | 5m | 6m |
| PT-CE39-W60A-A00I | 6600±10% | 422 | 211 | 188 | 155 | 111 | 76 | ≥80a | 5600- 7000K |
| PT-CE39-T60A-A00I | 6400±10% | 405 | 200 | 178 | 145 | 99 | 65 | ≥80a | 3800- 4500K |
| PT-CE39-L60A-A00I | 6250±10% | 399 | 195 | 167 | 133 | 88 | 55 | ≥80a | 2700- 3500K |
Package:
| Part No. | Net weight | Box | Carton |
| Size (mm) | Gross weight | Pcs/ box | Size(mm) | Gross weight | box/ carton |
| PT-C39-X60A-A00I | 1.34Kg | L365*W150*H145 | 1.45Kg | 1 | L650*W350*H395 | 13.5kg | 8 |
