GL12/20 Overview:
GL is a creative led screen with extremely high transparency, achieving a brilliant visual effect. GL screen can be applied on the building for advertising and decoration, as well as been hung up for rental application as display screen. 320x640mm for each panel size, only 5kg on weight for single panel, max thickness is 49 mm, all those unique advantages make GL a perfect choice for creative designing company to use on large-scale applications.
Main Features:
1. High transparency: 70% on transparency makes the led bulbs almost invisible above a specific distance on screen.
2. Flexible installation methods for various projects.
3. Lightweight body, single-person handling, easy transportation for touring shows.
4. Can be sticked on windows directly by special glue. Glue is easy to dry, without changing or damaging for buildings.
5. Perfect solutions for window facade, good daylighting, nice decoration and great advertising board.
6. High light transmittance: Light can get through screens easily.
7. Could achieve any arc-shaped within +/-10.
|
Item Name |
GL12 |
GL20 |
|
Pixel Pitch |
12.5mm |
20mm |
|
LED Type |
RGB 3in1 SMD3535 |
RGB 3in1 SMD3535 |
|
Pixel Density/sqm |
48x24 |
32x16 |
|
Pixel matrix per panel |
6400 |
2500 |
|
Panel Size |
300x600x49mm |
320x640x49mm |
|
Weight |
5kg |
5.5kg |
|
Protection Level |
IP20 or IP54 |
IP20 or IP54 |
|
Brightness |
4500 nit |
4500 nit |
|
Best Viewing Distance |
12m |
20m |
|
Transparency |
≥70% |
≥70% |
|
Viewing Angle |
H140° V140° |
|
LED Lamp/Chip |
Silar or Epistar |
|
Gray Rate |
14bit |
|
Colors |
687 Billion |
|
Max Power Consumption |
125 W/panel |
|
Ave. Power Consumption |
60 W/panel |
|
Refresh Rate |
≥1200Hz |
|
Gamma Parameter |
-5.0~+5.0 |
|
Application |
Outdoor;Rental&fixed use |
|
Input Signal |
DVI,VGA,HD-SDI,S-video,Composite,YUV,etc |
|
Input Voltage |
DC 36-75v,FSP.Technology Inc. |
|
Power Supply |
Meanwell or G-energy with UL certificate |
|
Display Media |
Video,graphic,animation,signage,cartoon,text,etc |
|
Control System |
YDEA(showbox),PC based dynamic capture & mapping. |
|
System Operating Platform |
WINDOW98/2000/XP/7/8 |
|
Working Environment |
Temperature: -10ºC~+50ºC, humidity: 10-90%RH |
|
Warranty |
Two years |
|
Lifetime |
> 50,000 hours(to>70% luminous output) |
|
Certificate |
CE&RoHs |
SHENZHEN VTEAM Co., Ltd. is a professional ODM LED Screen manufacturer in Shenzhen, China, specialized in creative indoor and outdoor LED screen with experienced R&D team who has been working in LED display field for more than 8 years.
VTEAM screen is popular with the features of light weight, ultra-thin cabinet, transparent structures and widely-used in the application of TV Station, studios, auto shows, music concerts, clubs, discos, building facade, outdoor decorative lighting projects, exhibitions, celebrations etc.
As one of leaders of LED Screen suppliers in China, All products carry CE RoHS certification, with perfect designed products, customized solution, superior product and service guarantee, VTEAM has been highly praised by domestic and overseas customers, we have been shipping qualified products and services to more than 100 countries and regions all over the world, such as in the USA, Russia, Germany, Sweden, France, Netherland, Spain, Canada, Brazil, Mexico etc. The most notable of those successful projects is that we have done the creative "Giant Football" for the opening&closing ceremony of 2014 Brazil FIFA WORLD CUP!
VTEAM Mission: To create value and profit for customers!
VTEAM Vision: Being creative concept pioneer!
