DC12V SMD3528 7.2W/M 12mm Flexible LED Strip Light with CE Certificate
1.LED: SMD 3528 high lumen high CRI LED
2. LED Quantity:90pcs/M
3. Circuit Board: Flexible Print Circuit Board(FPC)
4. Special Design: there are 90 pieces of LED on one meter strip.
Every 3 pieces of LED constitutes one 33.4mm long unit with a max watt of 0.24W and one meter strip has 30 units.Each unit or several units can be cutted from the line to use independently as a short strip.
5. Power(watt): Max 7.2W/Meter when the current is 20mA.The watt will lower down when the current sets to be lower
6. Working Current: Max 20mA.
Current is sincerely suggested to be lower than 20mA.
The Strip can be designed to produce constant-current strips to have a better stable brightness.
7. Input Voltage:DC12V. The light should connect with 12V external power supply. Direct connecting with electrcity is forbidden. The input voltage for the power supply is 85-265V, which means this light strip can be used in all the countries all over the world.
8. Strip width: 12mm(width ranges from 5mm to 18mm)
9. Avaliable Color Temperature:2700-10000K(Yellow, White,Blue, Red, Green, Purple and etc)
2700K-4000K(Warm White)
4500K-5500K (White)
6500K-10000K(Cold White)
10.CRI:there are three grades can be choosed:>75,>80,>90,With higher CRI, More Pure Color
11. Power Efficiency::≥90lm/W
12. The strip can be supplied with 3M self-adhesive tape on the back for the convenience of installing.
13. IP44,Indoor Use Only.
The strip can also be supplied with transparent epoxy layer on the surface of the strip to reach IP66. Or The strip can be covered by transparent silicon sleeve outside And the protection grade upgrade to IP67. It can be waterproof and can be used outdoor
14.Max Length:5M/strip.
The strip will be packaged in a round roll with max 5 meters one roll.
15. Lifespan: 30000hours
16. Warranty: 2 years.
17.Standard Packaging:In round reel with sealed plastic bag.
Attention:This strip can be supplied two ends with female and male joint for strip length above 5 meters, o it can be supplied with common black and red wire on one end.
Main Application
1.Light-Box lighting: Install around and behind the light box to get a better brightness.
2.Commercial Cabinet Lighting. Installed in the cabinets and stores as commercial lighting
3.Display Lighting. Use behind the display board to make it more bright and effective.
4.Decorative lighting. Use Colorful lights as decoration
5.General Lighting used as replacement of common lights.
6.Advertising Lighting. Use flexible strips to make different attractive letters.
7.Other Special Application
Below is the common product list of SMD3528 Flexible Strip Light:
| LED/M | Voltage | Current | Max Watt | Width |
| 60pcs/m | DC 12V | ≤ 20mA | 4.8W/m | 5-15mm |
| 90pcs/m | DC 12V | ≤ 20mA | 7.2W/m | 5-15mm |
| 120pcs/m | DC 12V | ≤ 20mA | 9.6W/m | 5-15mm |
| 180pcs/m | DC 12V | ≤ 20mA | 14.4W/m | 5-15mm |
| 60pcs/m | DC 24V | ≤ 20mA | 4.8W/m | 5-15mm |
| 84pcs/m | DC 24V | ≤ 20mA | 7.2W/m | 5-15mm |
| 120pcs/m | DC 24V | ≤ 20mA | 9.6W/m | 5-15mm |
| 180pcs/m | DC 24V | ≤ 20mA | 14.4W/m | 5-15mm |
