High Resolution SMD outdoor P5 Module, Stable Quality, Wholesale LED Display
High Quality LED Display, LED Video Wall. High Resolution, High Brightness, Stable Quality and Energy-saving. CE, RoHS, FCC Certificate
GLELED Co.,LIMITED
GLELED CO.,LIMITED is one of the leading professional high-tech enterprises which specialized in LED display with registered capital 10 million RMB. After ten years' efforts, we have become one of professional global LED product suppliers, which can provide the best LED solutions for customers. At present, we have one skilled R&D team and a production line of highest automatic degree; Our LED products have achieved ISO9001-2008, 3C, CE Certificate, etc.
Our company always implements our development target and insists on the tenet of " Services and Demand is the First ". Our company has a perfect after-sales service system, truly realizing that customers are the centers of the market marketing model.
Through our efforts, our products have been sold well in Europe, North America, Australia, the Middle East and Southeast Asia. Our company has set up stable sales agents in the corresponding areas. Our company sincerely hope to cooperate with LED display system talents and dealers for common development and for the development of LED display systems
Our products cover indoor and outdoor full color LED screen, cabinet module, panel, and LED bare lamp.
Our LED products have the below advantages:
1. LED chip: the chip brand is Epistar and make big size LED chip , compared with other manufacturers, the lifetime is much more longer and more stable performance. Great Reduce the dead LED rate.
2. Mask: Unique design with patent makes it more orderly and better visual effect as well as better waterproof effects. The screw is longer than others, which can prevent the mask falling off.
3. The PCB board is thicker , which can postpone corrosion. Also, cement conduct can be waterproof.
4. All the Key material is import from Taiwan or Japan, to ensure all component performance is stable and long lifetime.
5. Focus Our Brand, Try our best to build an trustable brand to our Customers.
6. Provide Customerized solution to meet different using- eviroment.
| High Resolution SMD outdoor p5 Module, Stable Quality, Wholesale LED Display |
| Item | Unit | Parameter |
| Pixel Pitch | mm | 5 |
| Pixel Density | dots/sqm | 40000 |
| Resolution of Module | dots | 32*16 |
| Module Size | mm | 320*160 |
| HUB | | 75b |
| Led Package | SMD3535 |
| Pixel Configuration | 1R1G1B |
| Chip Brand of LEDs | Epistar |
| Module Weight | kgs/pc | 0.36 |
| Brightness (White Balance) | nits(cd/m2) | 2,000 |
| Red Wavelength | nm | 620-625 |
| Green Wavelength | nm | 520-525 |
| Blue Wavelength | nm | 470-475 |
| Scan Mode | 1/8 scan |
| View Distance | M | 2~50 |
| Best View Distance | M | 2~30 |
| Viewing Angle-Horizontal | deg. | 120 |
| Viewing Angle-Vertical | deg. | 120 |
| Module Maximum Power | W | 33.4 |
| Max. Power Consumption | W/sq.m | 1000 |
| Avg. Power Consumption | W/sq.m | 350 |
| Working Voltage | AC 110V/220V input, DC5V output |
| Power Supply | AC 110/220V |
| Waterproof Grade | IP65 |
| Refresh Rate | Hz/S | 3,000 |
| Frame Rate | Hz/S | ≥ 60 |
| Gray Scale | 4096 grades gray |
| Display Color | 256*256*256 |
| Display Function | Text,news,advertising,flash,animation |
| Input Signal | RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc. |
| Luminance Degradation | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25 |
| Defective Dot Rate | | < 0.0001 |
| Life Span | hours | 100,000 |
| MTBF | hours | > 10,000 |
| Storage Temperature | | -35 -- +80 |
| Working Temperature | | -20 -- +80 |
| Working Humidity | 10%-90%RH |
| Control System | Synchronization or Asynchronization |
| Quality Certificate | ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008 |
| Warrenty | 2 Years |
| Working Environment | Outdoor |
| Other Fertures | LED&ICs in Departed PCB |
| Note: The above parameter is just for reference. Change can be made by customer requirement |
Channel Cailiang (Zhangzhou) Optoelectronic Co., Ltd. is one of the biggest LED manufacture in China. Our factory have 30 PCS production line for Outdoor DIP Modules, 5 PCS line for Indoor SMD products and more than 1, 500 skilled workers. Our R&D team are comprised of a crew of 10% of total staff and most of engineers have more than 5 years experience in LED industry, which great support our new products developing or customized products according to customers' requests.
Our Main Business is Produce various LED Display Module and LED Display Panel for Customers' assemble. It' s avaliable supply all the components for assemble LED Display or LED Message Signs. Besides, we focus on offering whole proposal for LED Display Projects and Solutions. Not only for regualr type, we have continuously developed several Profiled Screens and achieved some proud success in developing Traffic Wireless Solution Display Screens.
In order to design and develop higher quality products, our R&D team always tries best to meet the US&Euro-standards for Electronic products, as well as to fulfill the special requirements from customers. Our products have been approved the German TUV- EMC Certification and Euro EN12966 Certification, and we have also achieved ISO9001: 2000, CCC, CE, FCC, RoHS Certifications.
with perfect designed products, integrated solution including both hardware and software, and superior product and service guarantee, Cailiang has been highly praised by domestic and overseas customers. We have been shipping qualified products and services to more than 50 countries and regions all over the world, such as in the USA, Japan, Russia, Sweden, Turkey, Poland, France, Israel, Argentina, Spain, Italy, etc.
We value the power of cooperative team work, we take "Quality & Honesty" as our belief, and "Being the Largest Global Supplier of LED display Solution" as our goal.
"Channel Cailiang" Sincererly Invite your participation!
