| Price: | US $ 500/Piece |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
Main Parameter | ||
Category | Parameter | |
| Pixel Pitch | 16mm | |
| Optimum Viewing Distance | 16-40m | |
| Density of Pixel | 3906pixels/ | |
| Brightness | ≥8000nite | |
| Module Resolution | 16*16 | 20*20 |
| LED Encapsulation | SMD5050 1R1G1B | DIP346 2R1G1B |
| Driving Method | Real Static | Real Static |
| Optimum Viewing Angle | H: 120°V:100° | H: 110°V:50° |
| Module Size | 256*256*18(mm) | 320*320*27.3(mm) |
| Module Power | 60w | 50w |
| Module Weight | 1100g | 1200g |
| Cabinet Size | 1024*768mm or 960*960*150 or 1280*1280(mm) | |
| Cabinet Resolution | 64*48 60*60 80*80 | |
| Cabinet Power | 980w/sqm | 1000w/sqm |
| Cabinet Weight | 45kg/sqm | 49kg/sqm |
| IP Rating | Front/Rear:IP65/IP43 | |
| Refresh Rate | 1000-4000Hz(Different according to the different Driving IC) | |
| Luminance Degradation | Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25ºC. | |
| MTBF | >5000hours | |
| Defective Dot Rate | <0.0001 | |
| Life Span | >100000hours | |
| Working Voltage | 110-240 AC±10% 50-60Hz | |
| Working Temperature/Humidity | -30ºC - +50ºC/10-90%RH | |
Storage Temperature/Humidity | -40ºC - +60ºC/10- 90%RH | |
Input Signal | RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc | |
Connector | CAT5 Cable(Length≤1430m),Optical link( Length≤20km,Optional) | |
| Note: The above parameter is just for reference. Changes can be made according to customers' requirements. | ||
| Prod Model: | MYLED16 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Apple4s ( 8 Inch): | Apple 5s (10 Inch) |
| Tube Chip Color: | Full Color |
| Display Function: | Video Display |
| Pixel Pitch: | 10mm |
| Pixel Configuration: | 1R,1G,1B |
| Pixel Density: | 10,000 dots / m² |
| Scanning Mode: | 1/16 Scan |
| System Operating Platform: | WIN XP |
| Display Type: | LED Video Display |
| Application: | Shopping Guide |
